The AD8452 combines a precision analog front-end controller and switch mode power supply (SMPS), pulse-width modulator (PWM) driver into a single silicon platform for high volume battery testing and formation manufacturing. A precision instrumentation amplifier (in-amp) measures the battery charge/discharge current, while an equally accurate difference amplifier measures the battery voltage. Internal laser trimmed resistor networks establish the in-amp and difference amplifier gains (66 V/V and 0.4 V/V, respectively), and stabilize the AD8452 performance across the rated operating temperature range.Desired battery cycling current and voltage levels are established by applying precise control voltages to the ISET and VSET inputs. Actual charge and discharge current levels are sensed (usually by a high power, highly accurate shunt resistor) whose value is carefully selected according to system parameters. Switching between constant current (CC) and constant voltage (CV) loop integration is instantaneous, automatic, and completely transparent to the observer. A logic high at the MODE input selects the charge or discharge mode (high for charge, low for discharge).The AD8452 simplifies designs by providing excellent performance, functionality, and overall reliability in a space saving 48-lead, 7 mm ? 7 mm ? 1.4 mm LQFP package rated for operation at temperatures from ?40?C to +85?C.Applications Battery formation and testing High efficiency battery test systems with recycle capability Battery conditioning (charging and discharging) systems

The AD9833 is a low power, programmable waveform generator capable of producing sine, triangular, and square wave outputs. Waveform generation is required in various types of sensing, actuation, and time domain reflectometry (TDR) applications. The output frequency and phase are software programmable, allowing easy tuning. No external components are needed. The frequency registers are 28 bits wide: with a 25 MHz clock rate, resolution of 0.1 Hz can be achieved; with a 1 MHz clock rate, the AD9833 can be tuned to 0.004 Hz resolution.The AD9833 is written to via a 3-wire serial interface. This serial interface operates at clock rates up to 40 MHz and is compatible with DSP and microcontroller standards. The device operates with a power supply from 2.3 V to 5.5 V.The AD9833 has a power-down function (SLEEP). This function allows sections of the device that are not being used to be powered down, thus minimizing the current consumption of the part. For example, the DAC can be powered down when a clock output is being generated.The AD9833 is available in a 10-lead MSOP package.Applications Frequency stimulus/waveform generation Liquid and gas flow measurement Sensory applications: proximity, motion, and defect detection Line loss/attenuation Test and medical equipment Sweep/clock generators Time domain reflectometry (TDR) applications

The ADA4098-1?and ADA4098-2?are single/dual robust, precision, rail-to-rail input and output operational amplifiers (op amps) with inputs that operate from ?VS to +VS and beyond, which is referred to in this data sheet as Over-The-Top?. The devices feature offset voltages of ?VS, independent of the +VS supply.The ADA4098-1 and ADA4098-2 are unity-gain stable and can drive loads requiring up to 20 mA per channel. The devices can also drive capacitive loads as large as 200 pF. The amplifiers are available with low power shutdown.The ADA4098-1 is available in a standard, 6-lead thin small outline transistor (TSOT) package. The ADA4098-2 is available in an 8-lead standard small outline (SOIC_N) package, 8-lead mini small outline package (MSOP), and 10-lead lead-frame chip-scale package (LFCSP).APPLICATIONS Industrial sensor conditioning Supply current sensing Battery and power supply monitoring Front-end amplifiers in abusive environments 4 mA to 20 mA transmitters

The ADA4522-1 / ADA4522-2 / ADA4522-4 are single/dual/quadchannel, zero drift op amps with low noise and power, groundsensing inputs, and rail-to-rail output, optimized for totalaccuracy over time, temperature, and voltage conditions. Thewide operating voltage and temperature ranges, as well as thehigh open-loop gain and very low dc and ac errors make thedevices well suited for amplifying very small input signals andfor accurately reproducing larger signals in a wide variety ofapplications.The ADA4522-1 / ADA4522-2 / ADA4522-4 performance isspecified at 5.0 V, 30 V, and 55 V power supply voltages. Thesedevices operate over the range of 4.5 V to 55 V, and are excellentfor applications using single-ended supplies of 5 V, 10 V, 12 V,and 30 V, or for applications using higher single supplies anddual supplies of ?2.5 V, ?5 V, and ?15 V. The ADA4522-1 / ?ADA4522-2 / ADA4522-4 use on-chip filtering to achieve highimmunity to electromagnetic interference (EMI).The ADA4522-1 / ADA4522-2 / ADA4522-4 are fully specifiedover the extended industrial temperature range of ?40?C to+125?C and are available in 8-lead MSOP, 8-lead SOIC, 14-leadSOIC, and 14-lead TSSOP packages.APPLICATIONS Inductance, capacitance, and resistance (LCR) meter/megohmmeter front-end amplifiers Load cell and bridge transducers Magnetic force balance scales High precision shunt current sensing Thermocouple/resistance temperature detector (RTD) sensors Programmable logic controller (PLC) input and output amplifiers

The ADATE324 is a complete, single-chip, quad-channel automatic test equipment (ATE) solution that performs the pin electronics (PE) functions of a driver, a comparator, and an active load (DCL). The device also features a high voltage (VHH) drive capability per chip to support flash memory testing applications. Dedicated 16-bit digital-to-analog converters (DACs) with on-chip calibration registers provide all the necessary dc levels for operation of the device.The voltage driver features three active states: high, low, and terminate mode, as well as a high impedance inhibit state. The inhibit state, in conjunction with the integrated dynamic clamps, facilitates significant attenuation of transmission line reflections when the driver is not actively terminating the line. The open circuit drive capability is ?1.5 V to +4.5 V to accommodate the standard range of ATE and instrumentation applications.The ADATE324 can be used as a quad, single-ended, pin electronics channel or as a dual differential channel. In additional to per channel, high speed window comparators, the ADATE324 provides two programmable threshold differential comparators for differential ATE applications.All dc levels for DCL functions are generated by dedicated on-chip 16-bit DACs. To facilitate accurate programming levels, the ADATE324 also includes an integrated calibration function to correct for gain and offset errors of each functional block. Correction coefficients can be stored on chip, and any values written to the DACs are automatically adjusted using the appropriate correction factors.The ADATE324 uses a serial programmable interface (SPI) bus to program all functional blocks, DACs, and on-chip calibration constants. The device also has an on-chip temperature sensor, and overvoltage and undervoltage fault clamps, for monitoring and reporting the device temperature, and any output pin voltage faults that may occur during operation.For more information on the ADATE324, contact ADATE324@analog.com.APPLICATIONS ATE Semiconductor and board test systems Instrumentation and characterization equipment

The ADAU1442 / ADAU1445?/ ADAU1446?are enhanced audio processors that allow full flexibility in routing all input and output signals. The SigmaDSP? core features full 28-bit processing (56-bit in double-precision mode), synchronous parameter loading for ensuring filter stability, and 100% code efficiency with the SigmaStudio? tools. This DSP allows system designers to compensate for the real-world limitations of speakers, amplifiers, and listening environments, resulting in a dramatic improvement of the perceived audio quality through speaker equalization, multiband compression, limiting, and third-party branded algorithms.The flexible audio routing matrix (FARM) allows the user to multiplex inputs from multiple sources running at various sample rates to or from the SigmaDSP core. This drastically reduces the complexity of signal routing and clocking issues in the audio system. FARM includes up to eight stereo asynchronous sample rate converters (depending on the device model), Sony/ Philips Digital Interconnect Format (S/PDIF) input and output, and serial (I2S) and time division multiplexing (TDM) I/Os. Any of these inputs can be routed to the SigmaDSP core or to any of the asynchronous sample rate converters (ASRCs). Similarly, any one of the output signals can be taken from the SigmaDSP core or from any of the ASRC outputs. This routing scheme, which can be modified at any time via control registers, allows for maximum system flexibility.The ADAU1442, ADAU1445, and ADAU1446 differ only in ASRC functionality and packaging. The ADAU1442 / ADAU1445 contain 16 channels of ASRCs and are packaged in TQFP packages, whereas the ADAU1446 contains no ASRCs and is packaged in an LQFP. The ADAU1442 can handle nine clock domains, the ADAU1445 can handle three clock domains, and the ADAU1446 can handle one clock domain.The ADAU1442 / ADAU1445 / ADAU1446?can be controlled in one of two operational modes: the settings of the chip can be loaded and dynamically updated through the SPI/I2C? port, or the DSP can self-boot from an external EEPROM in a system with no microcontroller. There is also a bank of multipurpose (MP) pins that can be used as general-purpose digital I/Os or as inputs to the 4-channel auxiliary control ADC.The ADAU1442 / ADAU1445 / ADAU1446?are supported by the SigmaStudio graphical development environment. This software includes audio processing blocks such as FIR and IIR filters, dynamics processors, mixers, low level DSP functions, and third-party algorithms for fast development of custom signal flows.APPLICATIONS Automotive audio processing Head units Navigation systems Rear-seat entertainment systems DSP amplifiers (sound system amplifiers) Commercial audio processing

The ADAU1761 is a low power, stereo audio codec with integrated digital audio processing that supports stereo 48 kHz record and playback at 14 mW from a 1.8 V analog supply. The stereo audio ADCs and DACs support sample rates from 8 kHz to 96 kHz as well as a digital volume control.The SigmaDSP? core features 28-bit processing (56-bit double precision). The processor allows system designers to compensate for the real-world limitations of microphones, speakers, amplifiers, and listening environments, resulting in a dramatic improvement in the perceived audio quality through equalization, multiband compression, limiting, and third-party branded algorithms.The SigmaStudio? graphical development tool is used to program the ADAU1761. This software includes audio processing blocks such as filters, dynamics processors, mixers, and low level DSP functions for fast development of custom signal flows.The record path includes an integrated microphone bias circuit and six inputs. The inputs can be mixed and muxed before the ADC, or they can be configured to bypass the ADC. The ADAU1761 includes a stereo digital microphone input.The ADAU1761 includes five high power output drivers (two differential and three single-ended), supporting stereo head-phones, an earpiece, or other output transducer. AC-coupled or capless configurations are supported. Individual fine level controls are supported on all analog outputs. The output mixer stage allows for flexible routing of audio.APPLICATIONS Smartphones/multimedia phones Digital still cameras/digital video cameras Portable media players/portable audio players Phone accessories products

The ADBMS18181 is a multicell battery stack monitor that measures up to 18 series connected battery cells with a total measurement error of less than 3.0 mV. The cell measurement range of 0 V to 5 V makes the ADBMS1818 suitable for most battery chemistries. All 18 cells can be measured in 290 ?s, and lower data acquisition rates can be selected for high noise reduction. Multiple ADBMS1818 devices can be connected in series, permitting simultaneous cell monitoring of long, high voltage battery strings. Each ADBMS1818 has an isoSPI? interface for high speed, RF immune, long distance communications. Multiple devices are connected in a daisy chain with one host processor connection for all devices. This daisy chain can be operated bidirectionally, ensuring communication integrity, even in the event of a fault along the communication path. The ADBMS1818 can be powered directly from the battery stack or from an isolated supply. The ADBMS1818 includes passive balancing for each cell, with individual PWM duty cycle control for each cell. Other features include an on-board 5 V regulator, nine general purpose I/O lines, and a sleep mode, where current consumption is reduced to 6 ?A. All registered trademarks and trademarks are the property of their respective owners. 1 Protected by multiple U.S. patents, including 8908779, 9182428, and 9270133. APPLICATIONS Backup battery systems Grid energy storage Residential energy storage UPS High power portable equipment

The ADBMS6816 is a multicell battery stack monitor that measures up to six series connected battery cells with a lifetime total measurement error (TME) of less than 1.5 mV. The cell measurement range of 0 V to 5 V makes the ADBMS6816 suitable for most battery chemistries. All six cells can be measured in 304 ?s, and lower data acquisition rates can be selected for high noise reduction.Multiple ADBMS6816 devices can be connected in series, permitting simultaneous cell monitoring of long, high voltage battery strings. Each ADBMS6816 has an isoSPI? interface for high speed, RF immune, long distance communications.Multiple devices are connected in a daisy chain with one host processor connection for all devices. This daisy chain can be operated bidirectionally, ensuring communication integrity even in the event of a fault along the communication path.The ADBMS6816 can be powered directly from the battery stack or from an isolated supply. The ADBMS6816 includes passive balancing for each cell, with individual pulse-width modulation (PWM) duty cycle control for each cell. Other features include an on-board 5 V regulator, seven general-purpose input/output (GPIO) lines, and a sleep state, where current consumption is reduced to 5.5 ?A.APPLICATIONS Electric and hybrid electric vehicles Backup battery systems Grid energy storage High power portable equipment

The ADCMP551 / ADCMP552?/ ADCMP553?are single supply,high speed comparators fabricated on Analog Devices?proprietary XFCB process. The devices feature a 750 ps propagation delay with less than 150 ps overdrive dispersion. Dispersion, a measure of the difference in propagation delay under differing overdrive conditions, is a particularly importantcharacteristic of high speed comparators. A separateprogrammable hysteresis pin is available on the ADCMP552.A differential input stage permits consistent propagation delay with a common-mode range from ?0.2 V to VCCI ? 2.0 V. Outputs are complementary digital signals are fully compatible with PECL 10 K and 10 KH logic families. The outputs providesufficient drive current to directly drive transmission lines terminated in 50 ? to VCCO - 2 V. A latch input is included and permits tracking, track-and-hold, or sample-and-hold modes of operation. The latch input pins contain internal pullups that set the latch in tracking mode when left open. The ADCMP551 / ADCMP552 / ADCMP553 are specified over the ?40?C to +85?C industrial temperature range. TheADCMP551 is available in a 16-lead QSOP package; theADCMP552 is available in a 20-lead QSOP package; and the ADCMP553 is available in an 8-lead MSOP package.APPLICATIONS Automatic test equipment High speed instrumentation Scope and logic analyzer front ends Window comparators High speed line receivers Threshold detection Peak detection High speed triggers Patient diagnostics Disk drive read channel detection Hand-held test instruments Zero crossing detectors Line receivers and signal restoration Clock drivers
