LTM4630EY-1 Demo Board | 2 Paralleled Buck μModules, 4.5V ≤ VIN ≤ 15V, VOUT = 0.9V to 1.8V @ 70A
Analog Devices Inc.
Demonstration Circuit 2164A-A features a PolyPhase® design using two paralleled LTM4630EY-1's (A-grade), the high efficiency, high density, dual 18A, switch mode step-down power module regulator. The input voltage is from 4.5V to 15V. The output voltage is jumper selectable and can be set to 0.9V, 1.0V, 1.2V, 1.5V or 1.8V. DC2164A-A can deliver nominal 70A output current. As explained in the data sheet, output current derating is necessary for certain VIN, VOUT, and thermal conditions. The LTM4630-1A on DC2164A-A always operate in continuous conduction mode. The switching frequency can be programmed through a resistor or can be synchronized to an external clock signal. The board allows the user to program how its output voltage ramps up and down through the TRACK pin.
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | DC2164A-A-ND | 1 | $123.59 | $123.59 | $123.59 | $123.59 | $123.59 | $123.59 | |
| Analog Devices Inc | DC2164A-A | 0 | $123.59 | $123.59 | $123.59 | $123.59 | $123.59 | $123.59 | |
| Arrow North American Components | DC2164A-A | 0 | 1 | $100.80 | $100.80 | $100.80 | $100.80 | $100.80 | $100.80 |
| Mouser Electronics | 584-DC2164A-A | 0 | 1 | $127.91 | $127.91 | $127.91 | $127.91 | $127.91 | $127.91 |
| Verical Marketplace | DC2164A-A | 24 | 1 | $121.74 | $0.00 | $0.00 | $0.00 | $0.00 | $0.00 |
Manufacturer Page
LTC3526LEDC Demo Board | 1MHz, 0.8V ≤ VIN ≤ 5.5V, VOUT = 1.8V/3.3V/5V @ 100mA
Analog Devices Inc.
Demonstration circuits 1053A-E through 1053A-H exercise the LTC3526L family of high efficiency synchronous boost converters, and are capable of operating with an input voltage range from 0.8V to 5.5V. The 2 × 2 mm DFN thermally enhanced package, high switching frequency (1MHz or 2MHz) and 550mA internal power switches provide a very tiny solution. The LTC3526L family also features output disconnect, and the input voltage can be greater or less than the output voltage. DC1053A-E features the LTC3526L (Burst mode operation) and the DC1053A-F features the LTC3526LB (Burst mode defeated). Both have a 1MHz switching frequency and use a 4.7µH inductor.
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | DC1053A-E-ND | 3 | $88.28 | $88.28 | $88.28 | $88.28 | $88.28 | $88.28 | |
| Analog Devices Inc | DC1053A-E | 0 | $88.28 | $88.28 | $88.28 | $88.28 | $88.28 | $88.28 | |
| Mouser Electronics | 584-DC1053A-E | 4 | 1 | $91.36 | $91.36 | $91.36 | $91.36 | $91.36 | $91.36 |
LTC3526LEDC-2 Demo Board | 2MHz, 0.8V ≤ VIN ≤ 5.5V, VOUT = 1.8V/3.3V/5V @ 100mA
Analog Devices Inc.
Demonstration circuits 1053A-E through 1053A-H exercise the LTC3526L family of high efficiency synchronous boost converters, and are capable of operating with an input voltage range from 0.8V to 5.5V. The 2 × 2 mm DFN thermally enhanced package, high switching frequency (1MHz or 2MHz) and 550mA internal power switches provide a very tiny solution. The LTC3526L family also features output disconnect, and the input voltage can be greater or less than the output voltage. DC1053A-G features the LTC3526L-2 (Burst mode operation) and the DC1053A-H features the LTC3526LB-2 (Burst mode defeated). Both have a 2MHz switching frequency and use a 2.2µH inductor.
