The ADG5412/ADG5413 contain four independent single-pole/single-throw (SPST) switches. The ADG5412 switches turn onwith Logic 1. The ADG5413 has two switches with digital controllogic similar to that of the ADG5412; however, the logic is invertedon the other two switches. Each switch conducts equally well inboth directions when on, and each switch has an input signalrange that extends to the supplies. In the off condition, signallevels up to the supplies are blocked.The ADG5412 and ADG5413 do not have a VL pin. The digitalinputs are compatible with 3 V logic inputs over the full operatingsupply range.The on-resistance profile is very flat over the full analog inputrange, which ensures good linearity and low distortion whenswitching audio signals. High switching speed also makes thedevices suitable for video signal switching. The ADG5413exhibits break-before-make switching action for use inmultiplexer applications. Product Highlights Trench isolation guards against latch-up. A dielectric trench separates the P and N channel transistors thereby preventing latch-up even under severe overvoltage conditions. Low RON. Dual-supply operation. For applications where the analog signal is bipolar, the ADG5412/ADG5413 can be operated from dual supplies up to ?22 V. Single-supply operation. For applications where the analog signal is unipolar, the ADG5412/ADG5413 can be operated from a single rail power supply up to 40 V. 3 V logic compatible digital inputs: VINH = 2.0 V, VINL = 0.8 V. No VL logic power supply required. Applications Relay replacement Automatic test equipment Data acquisition Instrumentation Avionics Audio and video switching Communication systems

The ADG741 is a monolithic CMOS SPST switch. It is designed on an advanced submicron process that provides low power dissipation yet high switching speed, low on resistance, low leakage currents and -3 dB bandwidths of greater than 200 MHz can be achieved.The ADG741 can operate from a single 1.8 V to 5.5 V supply, making it ideal for use in battery-powered instruments and with Analog Devices' new generation of DACs and ADCs.APPLICATIONS Battery Powered Systems Communication Systems Sample Hold Systems Audio Signal Routing Video Switching Mechanical Reed Relay Replacement

The AD1030 is an analog front end (AFE) that includes a high precision analog-to-digital converter (ADC), voltage output digital-to-analog converters (VDACs), current output digital-to-analog converters (IDACs), thermoelectric cooler (TEC) controller, and analog comparators.The ADC signal chain contains two analog comparator channels, 10 external voltage inputs, VDAC voltage and current monitor channels, IDAC voltage and current monitor channels, a precharge buffer, and a 1 MSPS successive approximation register (SAR) ADC.The AD1030 provides four IDAC channels. These are low noise, low drift current sources with programmable full-scale output ranges (50 mA, 100 mA, or 150 mA). Each IDAC channel has 12-bit resolution.There are 9?, 12-bit VDAC outputs. Four of these VDACs (Channel 0 to Channel 3) support either a positive voltage range of 0 V to 2.5 V or a negative range from 0 V to ?2.5 V. These ranges can be extended to 0 V to AVDD and 0 V to AVDDNEG.Channel 4 to Channel 7 of the VDACs support a positive voltage range of 0 V to 2.5 V. VDAC Channel 8 supports a positive voltage range of 0 V to 2.5 V. Optionally, Channel 4 to Channel 7 of the VDACs can support an output range of 0 V to AVDD.The AD1030 also integrates a TEC controller with a heating and cooling current up to 1.3 A, is over 90% efficient, and supports a soft start function.Use the 4-wire serial port interface (SPI) for up to 40 MHz or the 2-wire I2C interface for up 1 MHz to configure each functional block and to collect the ADC data.APPLICATIONS Optical networking?100G/200G/400G or higher speed optical modulesFor more information on the AD1030, contact InfoOpticalNetwork@analog.com.

The AD4695/AD4696 are compact, high accuracy, low power, 16-channel, 16-bit, 500 kSPS/1 MSPS, multiplexed input precision, successive approximation register (SAR) analog-to-digital converters (ADCs) with Easy Drive features and extensive digital functionality.The AD4695/AD4696 are optimal for use in space constrained, multichannel, precision data acquisition systems and monitoring circuits. The AD4695/AD4696 feature a true 16-bit SAR ADC core with no missing codes, a 16-channel, low crosstalk multiplexer, a flexible channel sequencer, overvoltage protection clamp circuits on each analog input, on-chip oversampling and decimation, threshold detection and alert indicators, and an autonomous conversion (autocycle) mode.The AD4695/AD4696 Easy Drive features relax the drive requirements of the analog front end (AFE) and reference circuitry. Analog input high-Z mode and reference input high?Z mode simplify system designs, reduce component count, and increase channel density by removing the need for dedicated high speed ADC drivers and reference buffers. The WLCSP option of the AD4695/AD4696 includes an internal reference buffer, which provides a true, buffered reference input.Input overvoltage protection clamps on each analog input protect the AD4695/AD4696 from overvoltage events and prevent overvoltage events on one channel from degrading performance on other channels (see Figure 27 in the data sheet).Advanced digital functionality makes the AD4695/AD4696 compatible with a variety of low power digital hosts. The low serial peripheral interface (SPI) clock rate requirements, on-chip customizable channel sequencers, and oversampling and decimation reduce the burden on the digital host system. Autocycle mode and threshold detection features enable low power, interrupt driven firmware design by performing conversions autonomously and generating alerts based on channel specific threshold limits.The AD4695/AD4696 are available in a 5 mm ? 5 mm 32-lead lead frame chip scale package (LFCSP) and a 2.96 mm ? 2.96 mm 36-ball wafer level chip scale package (WLCSP) with operation specified from ?40?C to +125?C.APPLICATIONS Photodiode monitoring Medical instrumentation Vital signs monitoring Electronic test and measurement Automated test equipment Instrumentation and process control Battery-powered equipment

The Evaluation board for the AD5110 contains a SDP connection and software which allows the AD5110 to be controlled from an SDP board. This evaluation board requires an SDP Controller board for connection to the PC. The SDP controller board connects to the PC via USB 2.0. The evaluation board will connect to the SDP controller board. The evaluation board cannot be connected directly to the PC. The evaluation software running on the PC will communicate with the evaluation board through the SDP Controller board. The SDP Controller board is a separate list item in the ordering guide below (EVAL-SDP-CS1Z). If you have not previously purchased an SDP Controller board, please do so to ensure a full evaluation setup.

The AD5111 provides a nonvolatile solution for 128-position adjustment applications, offering guaranteed low resistor tolerance errors of ?8% and up to ?6 mA current density in the A, B, and W pins. The low resistor tolerance, low nominal temperature coefficient, and high bandwidth simplifyopen-loop applications, as well as tolerance matching applications.The new low wiper resistance feature minimizes the wiper resistance in the extremes of the resistor array to only 45 ? typical.A simple 3-wire up/down interface allows manual switching or high speed digital control with clock rates up to 50 MHz.The AD5111 is available in a 2 mm ? 2 mm LFCSP package. The parts are guaranteed to operate over the extended industrial temperature range of ?40?C to +125?C.APPLICATIONS Mechanical potentiometer replacement Portable electronics level adjustment Audio volume control Low resolution DAC LCD panel brightness and contrast control Programmable voltage to current conversion Programmable filters, delays, time constants Feedback resistor programmable power supply Sensor calibration

The AD5162 provides a compact 3 mm נ4.9 mm packaged solution for dual 256 position adjustment applications. This device performs the same electronic adjustment function as a 3-terminal mechanical potentiometer.Available in four different end-to-end resistance values (2.5 k?, 10 k?, 50 k?, 100 k?), this low temperature coefficient device is ideal for high accuracy and stability-variable resistance adjustments.The wiper settings are controllable through the SPI compatible digital interface. The resistance between the wiper and either end point of the fixed resistor varies linearly with respect to the digital code transferred into the RDAC latch.Operating from a 2.7 V to 5.5 V power supply and consuming less than 6 ?A allows the AD5162 to be used in portable battery-operated applications.For applications that program the AD5162 at the factory, Analog Devices offers device programming software running on Windows? NT/2000/XP operating systems. This software effectively replaces the need for external SPI controllers, which in turn enhances the time to market of systems. An AD5162 evaluation kit and software are available. The kit includes a cable and instruction manual.APPLICATIONS Systems calibrations Electronics level settings Mechanical trimmers replacement in new designs Permanent factory PCB setting Transducer adjustment of pressure, temperature, position, chemical, and optical sensors RF amplifier biasing Automotive electronics adjustment Gain control and offset adjustment

The AD5228 is Analog Devices? latest 32-step-up/step-down control digital potentiometer emulating mechanical potentiometer operation. Its simple up/down control interface allows manual control with just two external pushbutton tactile switches. The AD5228 is designed with a built-in adaptive debouncer that ignores invalid bounces due to contact bounce commonly found in mechanical switches. The debouncer is adaptive, accommodating a variety of pushbutton tactile switches that generally have less than 10 ms of bounce time during contact closures. When choosing the switch, the user should consult the timing specification of the switch to ensure its suitability in an AD5228 application.The AD5228 can increment or decrement the resistance in discrete steps or in autoscan mode. When the PU or PD button is pressed briefly (no longer than 0.6 s), the resistance of the AD5228 changes by one step. When the PU or PD button is held continuously for more than a second, the device activates the autoscan mode and changes four resistance steps per second.The AD5228 can also be controlled digitally; its up/down features simplify microcontroller usage. The AD5228 is available in a compact thin SOT-23-8 (TSOT-8) package. The part is guaranteed to operate over the automotive temperature range of ?40?C to +105?C.The AD5228?s simple interface, small footprint, and very low cost enable it to replace mechanical potentiometers and trimmers with typically 3? improved resolution, solid-state reliability, and faster adjustment, resulting in considerable cost saving in end users? systems.Users who consider EEMEM potentiometers should refer to the recommendations in the Applications section.APPLICATIONS Mechanical potentiometer and trimmer replacements LCD backlight, contrast, and brightness controls Digital volume control Portable device-level adjustments Electronic front panel-level controls Programmable power supply

The AD5235 is a dual-channel, nonvolatile memory, digitallycontrolled potentiometer with 1024-step resolution, offeringguaranteed maximum low resistor tolerance error of ?8%.The device performs the same electronic adjustment functionas a mechanical potentiometer with enhanced resolution, solidstate reliability, and superior low temperature coefficient performance.The versatile programming of the AD5235 via anSPI?-compatible serial interface allows 16 modes of operationand adjustment including scratchpad programming, memorystoring and restoring, increment/decrement, ?6 dB/step log taperadjustment, wiper setting readback, and extra EEMEM for user-definedinformation such as memory data for other components,look-up table, or system identification information.In the scratchpad programming mode, a specific setting canbe programmed directly to the RDAC register, which sets theresistance between Terminal W and Terminal A and Terminal Wand Terminal B. This setting can be stored into the EEMEMand is restored automatically to the RDAC register duringsystem power-on.The EEMEM content can be restored dynamically or throughexternal PR strobing, and a WP function protects EEMEMcontents. To simplify the programming, the independent orsimultaneous linear-step increment or decrement commandscan be used to move the RDAC wiper up or down, one step ata time. For logarithmic ?6 dB changes in the wiper setting, theleft or right bit shift command can be used to double or halve theRDAC wiper setting.The AD5235 patterned resistance tolerance is stored in theEEMEM. The actual end-to-end resistance can, therefore, beknown by the host processor in readback mode. The host canexecute the appropriate resistance step through a softwareroutine that simplifies open-loop applications as well asprecision calibration and tolerance matching applications.The AD5235 is available in a thin, 16-lead TSSOP package.The part is guaranteed to operate over the extended industrialtemperature range of ?40?C to +85?C.Applications DWDM laser diode driver, optical supervisory systems Mechanical potentiometer replacement Instrumentation: gain, offset adjustment Programmable voltage-to-current conversion Programmable filters, delays, time constants Programmable power supply Low resolution DAC replacement Sensor calibration

DC918C-M: Demo Board for the LTC2201 16-Bit, 20Msps ADC.
