The LT3573 is a monolithic switching regulator specifically designed for the isolated flyback topology. No third winding or opto-isolator is required for regulation. The part senses the isolated output voltage directly from the primary-side flyback waveform. A 1.25A, 60V NPN power switch is integrated along with all control logic into a 16-lead MSOP package.The LT3573 operates with input supply voltages from 3V to 40V, and can deliver output power up to 7W with no external power devices.The LT3573 utilizes boundary mode operation to provide a small magnetic solution with improved load regulation.Applications Industrial, Automotive and Medical Isolated Power Supplies

DC1251A-B: Demo Board for LTC6601-2 - Low Power, Low Distortion, Low Power, Low Distortion, 5MHz to 27MHz, Pin Configurable Filter/ADC Driver

The LTC1605 is a 100ksps, sampling 16-bit A/D converter that draws only 55mW (typical) from a single 5V supply. This easy-to-use device includes sample-and-hold, precision reference, switched capacitor successive approximation A/D and trimmed internal clock.The LTC1605?s input range is an industry standard ?10V. Maximum DC specs include ?2.0LSB INL and 16-bits no missing codes over temperature. An external reference can be used if greater accuracy over temperature is needed.The ADC has a microprocessor compatible, 16-bit or two byte parallel output port. A convert start input and a data ready signal (BUSY) ease connections to FIFOs, DSPs and microprocessors. Input Voltage Range LTC1605 Bipolar ?10V LTC1605-1 Unipolar 0V to 4V LTC1605-2 Bipolar ?4V Applications Industrial Process Control Multiplexed Data Acquisition Systems High Speed Data Acquisition for PCs Digital Signal Processing

DC1266A-A: Demo Board for the LTC2453 Ultra-Tiny, Differential, 16-Bit ∆Σ ADC With I2C Interface

Demonstration circuit 1267A is a step-up DC/DC regulator featuring the LTC3125EDCB and is ideally suited for pulsed load applications where the input current needs to be limited. Demonstration circuit 1267A is configured for 500mA maximum input current limit and can handle pulsed load currents of up to 2A, with duty cycles of up to 15%. The input voltage range is 3.3V ±10%.

The LTC1520 is a high speed, precision differential line receiver that can operate at data rates as high as 50Mbps. A unique architecture provides very stable propagation delays and low skew over a wide input common mode, input overdrive and ambient temperature range. Propagation delay is 18ns ?3ns, while typically tPLH/tPHL skew is 500ps and channel-to-channel skew is 400ps.Each receiver translates differential input levels (VID ? 100mV) into valid CMOS and TTL output levels. Its high input resistance (?18k) allows many receivers to be connected to the same driver. The receiver outputs go into a high impedance state when disabled.Protection features include thermal shutdown and a controlled maximum short-circuit current (50mA max) that does not oscillate in and out of short-circuit mode. Input resistance remains ?18k when the device is unpowered or disabled, thus allowing the LTC1520 to be hot swapped into a backplane without loading the data lines.The LTC1520 operates from a single 5V supply and draws 12mA of supply current. The part is available in a 16-lead narrow SO package.Applications High Speed Backplane Interface Line Collision Detector PECL and LVDS Line Receivers Level Translator Ring Oscillator Tapped Delay Line

DC1273A: Demo Board for LT1938 - 25V, 2.2A, 2.8MHz Step-Down Switching Regulator

Demonstration circuit 1294A exercises four adjustable linear regulators in parallel using the LT3080. A small 20 mΩ ballast resistor is required for parallel operation. A short PCB trace can easily serve that purpose. The paralleled devices provide up to 4.4A of output current at 3.3V. Architected as a precision current source and voltage follower, the LT3080 can be used in many applications requiring high current, adjustability to zero output, and no heat sink. The device brings out the collector of the pass transistor to allow low dropout operation when used with multiple supplies. The LT3080's output voltage can be programmed to any level between 0V and 36V; however the demo board has a reduced input voltage range from 3.8V to 25V due to the input capacitor voltage rating.

The ADA4922-1 is a differential driver for 16-bit to 18-bitanalog-to-digital converters (ADCs) that have differential inputranges up to ?20 V. Configured as an easy-to-use, single-ended-to-differentialamplifier, the ADA4922-1 requires no externalcomponents to drive ADCs. The ADA4922-1 provides essentialbenefits such as low distortion and high SNR that are requiredfor driving ADCs with resolutions up to 18 bits.With a wide supply voltage range (5 V to 26 V), high inputimpedance, and fixed differential gain of 2, the ADA4922-1 isdesigned to drive ADCs found to in a variety of applications,including industrial instrumentation. The ADA4922-1 is manufactured on Analog Devices, Inc.,proprietary, second-generation XFCB process that enables theamplifier to achieve excellent noise and distortion performanceon high supply voltages.The ADA4922-1 is available in an 8-lead 3 mm ? 3 mm LFCSPas well as an 8-lead SOIC package. Both packages are equippedwith an exposed paddle for more efficient heat transfer. TheADA4922-1 is rated to work over the extended industrialtemperature range, ?40?C to +85?C. Applications High voltage data acquisition systems Industrial instrumentation Spectrum analysis ATE Medical instruments

Demonstration circuit EVAL-LT8692S-AZ is an ultracompact 4 rail power supply featuring the LT8692S, a 42V quad monolithic synchronous step-down Silent Switcher®. The demo circuit is designed for 5V, 3.3V, 1.8V, and 1.2V outputs from a nominal 12V input. The 3.3V, 1.8V and 1.2V converters are powered from the high voltage buck regulator with 5V output, which is powered from a wide range of 6.2V to 42V input. The current capability is 2A for the channel 1, and 1A for the low voltage channels. Internal soft-start, individual current limit, independent enable for each channel simplify the complex design of quad-output power converters. All regulators can be synchronized to a common external clock input or internal oscillator of 2MHz. The table in the demo manual summarizes the performance of the demo board at room temperature. The circuit can be easily modified for different applications. The LT8692S data sheet gives a complete description of the part, operation and application information. The data sheet must be read in conjunction with the quick start guide for demo circuit EVAL-LT8692S-AZ.
