The ADIS16507 is a precision, miniature microelectromechanical?system (MEMS) inertial measurement unit (IMU) that includes?a triaxial gyroscope and a triaxial accelerometer. Each inertial?sensor in the ADIS16507 combines with signal conditioning?that optimizes dynamic performance. The factory calibration?characterizes each sensor for sensitivity, bias, alignment,?linear acceleration (gyroscope bias), and point of percussion?(accelerometer location). As a result, each sensor has dynamic?compensation formulas that provide accurate sensor?measurements over a broad set of conditions.The ADIS16507 provides a simplified, cost effective method for?integrating accurate, multiaxis inertial sensing into industrial?systems, especially when compared with the complexity and?investment associated with discrete designs. All necessary motion?testing and calibration are part of the production process at the?factory, greatly reducing system integration time. Tight orthogonal?alignment simplifies inertial frame alignment in navigation?systems. The serial peripheral interface (SPI) and register?structure provide a simple interface for data collection and?configuration control.The ADIS16507 is available in a 100-ball, ball grid array (BGA)?package that is approximately 15 mm ? 15 mm ? 5 mm.Applications Navigation, stabilization, and instrumentation Unmanned and autonomous vehicles Smart agriculture and construction machinery Factory/industrial automation, robotics Virtual/augmented reality Internet of Moving Things

Demonstration circuit 2898A is a dual DC/DC converter with a 13V to 40V input voltage range, two 12V outputs at 4A each featuring the LTM4655. The LTM4655 is a EN55022B compliant 40V, dual 4A or single 8A step-down or 50W inverting DC/DC μModule® regulator. The switching frequencies of both channels are set at 1.2MHz on DC2898A. If the output voltage collapses sufficiently due to an overload or short-circuit condition, the internal oscillator will foldback to one-fifth of the LTM4655’s programmed switching frequency, protecting the power switch from damage. Key features of this board include: SSFM Jumper for Spread Spectrum Options CLKIN Inputs for External Sync PGOOD Signals for Each Output The two channels can be paralleled for higher output current. See the data sheet for more information on setting up the board for paralleling the two outputs. The LTM4655 data sheet gives a complete description of the device, its operation and application information. The data sheet must be read in conjunction with the demo manual prior to working on or modifying DC2898A.

The AD7124-8 is a low power, low noise, completely integratedanalog front end for high precision measurement applications.The device contains a low noise, 24-bit ?-? analog-to-digitalconverter (ADC), and can be configured to have 8 differentialinputs or 15 single-ended or pseudo differential inputs. The onchiplow gain stage ensures that signals of small amplitude canbe interfaced directly to the ADC.One of the major advantages of the AD7124-8 is that it gives theuser the flexibility to employ one of three integrated powermodes. The current consumption, range of output data rates,and rms noise can be tailored with the power mode selected.The device also offers a multitude of filter options, ensuring thatthe user has the highest degree of flexibility.The AD7124-8 can achieve simultaneous 50 Hz and 60 Hzrejection when operating at an output data rate of 25 SPS (singlecycle settling), with rejection in excess of 80 dB achieved at loweroutput data rates.The AD7124-8 establishes the highest degree of signal chainintegration. The device contains a precision, low noise, lowdrift internal band gap reference and accepts an externaldifferential reference, which can be internally buffered. Otherkey integrated features include programmable low drift excitationcurrent sources, burnout currents, and a bias voltage generator,which sets the common-mode voltage of a channel to AVDD/2.The low-side power switch enables the user to power downbridge sensors between conversions, ensuring the absoluteminimal power consumption of the system. The device alsoallows the user the option of operating with either an internalclock or an external clock.The integrated channel sequencer allows several channels to beenabled simultaneously, and the AD7124-8 sequentially convertson each enabled channel, simplifying communication with thedevice. As many as 16 channels can be enabled at any time, achannel being defined as an analog input or a diagnostic suchas a power supply check or a reference check. This uniquefeature allows diagnostics to be interleaved with conversions.The AD7124-8 also supports per channel configuration. Thedevice allows eight configurations or setups. Each configurationconsists of gain, filter type, output data rate, buffering, andreference source. The user can assign any of these setups on achannel by channel basis.The AD7124-8 also has extensive diagnostic functionalityintegrated as part of its comprehensive feature set. Thesediagnostics include a cyclic redundancy check (CRC), signalchain checks, and serial interface checks, which lead to a morerobust solution. These diagnostics reduce the need for externalcomponents to implement diagnostics, resulting in reducedboard space needs, reduced design cycle times, and cost savings.The failure modes effects and diagnostic analysis (FMEDA) of atypical application has shown a safe failure fraction (SFF) greaterthan 90% according to IEC 61508.The device operates with a single analog power supply from 2.7 Vto 3.6 V or a dual 1.8 V power supply. The digital supply has arange of 1.65 V to 3.6 V. It is specified for a temperature rangeof ?40?C to +125?C. The AD7124-8 is housed in a 32-leadLFCSP package.Note that, throughout this data sheet, multifunction pins, suchas DOUT/RDY, are referred to either by the entire pin name orby a single function of the pin, for example, RDY, when onlythat function is relevant.Applications Temperature measurement Pressure measurement Industrial process control Instrumentation Smart transmitters

The AD6688-3000EBZ supports the AD6688-3000, a 14-bit, 3GSPS dual analog-to-digital converter (ADC). The device has an on-chip buffer and a sample-and-hold circuit designed for low power, small size, and ease of use. This device is designed support direct RF sampling analog signals of up to 5 GHz. The 3 dB bandwidth of the ADC input is greater than 9 GHz. The AD6688 is optimized for wide input bandwidth, high sampling rate, excellent linearity, and low power in a small package. This reference design provides all of the support circuitry required to operate the ADC in its various modes and configurations. It is designed to interface directly with the ADS7-V2EBZ data capture card, allowing users to download captured data for analysis. The device control and subsequent data analyses can now be done using the ACE software package.

The AD7981 is a 16-bit, successive approximation, PulSAR? analog-to-digital converter (ADC) designed for high temperature operation. The AD7981 is capable of sample rates of up to 600 kSPS while maintaining low power consumption from a single power supply, VDD. It is a fast throughput, high accuracy, high temperature, successive approximation register (SAR) ADC, packaged in a small form factor with a versatile serial port interface (SPI).On the CNV rising edge, the AD7981 samples an analog input, IN+, between 0 V and REF with respect to a ground sense, IN?. The reference voltage, REF, is applied externally and can be set independent of the supply voltage, VDD. The device power scales linearly with throughput.The SPI-compatible serial interface also features the ability, using the SDI input, to daisy-chain several ADCs on a single, 3-wire bus and provides an optional busy indicator. It is compatible with 1.8 V, 2.5 V, 3 V, or 5 V logic, using the separate supply, VIO.For space constrained applications, the AD7981 is available in a 10-lead mini small outline package (MSOP) with operation speci-fied from ?55?C to +175?C and 10-lead ceramic flat package (FLATPACK) with operation specified from ?55?C to +210?C. These packages are designed for robustness at extreme temperatures, including monometallic wire bonding, and are qualified for up to 1000 hours of operation at the maximum temperature rating.The AD7981 is a member of a growing series of high temperature qualified products offered by Analog Devices, Inc. For a complete selection of available high temperature products, see the high temperature product list and qualification data available at www.analog.com/hightemp.Applications Oil and gas exploration Avionics Heavy industrial High temperature environments Scientific instrumentation

The ADP2138 and ADP2139 are high efficiency, low quiescent current, synchronous step-down dc-to-dc converters. The ADP2139 has the additional feature of an internal discharge switch. The total solution requires only three tiny external components. When the MODE pin is set high, the buck regulator operates in forced PWM mode, which provides low peak-to-peak ripple for power supply noise sensitive loads at the expense of light load efficiency. When the MODE pin is set low, the buck regulator automatically switches operating modes, depending on the load current level. At higher output loads, the buck regulator operates in PWM mode. When the load current falls below a predefined threshold, the regulator operates in power save mode (PSM), improving light load efficiency.The ADP2138/ADP2139 operate on input voltages of 2.3 V to 5.5 V, which allows for single lithium or lithium polymer cell, multiple alkaline or NiMH cell, PCMCIA, USB, and other standard power sources. The maximum load current of 800 mA is achievable across the input voltage range.The ADP2138/ADP2139 are available in fixed output voltages of 3.3 V, 3.0 V, 2.8 V, 2.5 V, 1.8 V, 1.5 V, 1.2 V, 1.0 V, and 0.8 V. All versions include an internal power switch and synchronous rectifier for minimal external part count and high efficiency. The ADP2138/ADP2139 have internal soft start and they are internally compensated. During logic controlled shutdown, the input is disconnected from the output and the ADP2138/ADP2139 draw 0.2 ?A (typical) from the input source.Other key features include undervoltage lockout to prevent deep battery discharge, and soft start to prevent input current overshoot at startup. The ADP2138/ADP2139 are available in a 6-ball wafer level chip scale package (WLCSP).Applications PDAs and palmtop computers Wireless handsets Digital audio, portable media players Digital cameras, GPS navigation units

The LTC3370 is a highly flexible multioutput power supply IC. The device includes four synchronous buck converters, configured to share eight 1A power stages, each of which is powered from independent 2.25V to 5.5V inputs.The DC/DCs are assigned to one of eight power configurations via pin programmable C1-C3 pins. The common buck switching frequency may be programmed with an external resistor, synchronized to an external oscillator, or set to a default internal 2MHz clock.The operating mode for all DC/DCs may be programmed via the PLL/MODE pin for Burst Mode or forced continuous mode operation. A PGOODALL output indicates when all enabled DC/DCs are within a specified percentage of their final output value.To reduce input noise, the buck converters are phased in 90? steps. Precision enable pin thresholds facilitate reliable power-up sequencing. The LTC3370 is available in a 32-lead 5mm ? 5mm QFN package.Applications General Purpose Multichannel Power Supplies:?Automotive, Industrial, Distributed Power Systems

Demonstration circuit 2416A features the LTM8003, a 40V, 3.5A step-down μModule® Regulator. This demo circuit is configured to deliver a 5.0V output from an input voltage between 6.0V to 40V at a switching frequency of 2MHz. The wide input range of the LTM8003 allows a variety of input sources such as automotive batteries and industrial supplies. Under light load conditions, the available Burst Mode® operation supports high efficiency with low output ripple.

The AD9689 is a dual, 14-bit, 2.0 GSPS/2.6 GSPS analog-to-digital converter (ADC). The device has an on-chip buffer and a sample-and-hold circuit designed for low power, small size, and ease of use. This product is designed to support communications applications capable of direct sampling wide bandwidth analog signals of up to 5 GHz. The ?3 dB bandwidth of the ADC input is 9 GHz. The AD9689 is optimized for wide input bandwidth, high sampling rate, excellent linearity, and low power in a small package.The dual ADC cores feature a multistage, differential pipelined architecture with integrated output error correction logic. Each ADC features wide bandwidth inputs supporting a variety of user-selectable input ranges. An integrated voltage reference eases design considerations. The analog input and clock signals are differential inputs. The ADC data outputs are internally connected to four digital downconverters (DDCs) through a crossbar mux. Each DDC consists of multiple cascaded signal processing stages: a 48-bit frequency translator (numerically controlled oscillator (NCO)), and decimation rates. The NCO has the option to select preset bands over the general-purpose input/output (GPIO) pins, which enables the selection of up to three bands. Operation of the AD9689 between the DDC modes is selectable via SPI-programmable profiles.In addition to the DDC blocks, the AD9689 has several functions that simplify the automatic gain control (AGC) function in a communications receiver. The programmable threshold detector allows monitoring of the incoming signal power using the fast detect control bits in Register 0x0245 of the ADC. If the input signal level exceeds the programmable threshold, the fast detect indicator goes high. Because this threshold indicator has low latency, the user can quickly turn down the system gain to avoid an overrange condition at the ADC input. In addition to the fast detect outputs, the AD9689 also offers signal monitoring capability. The signal monitoring block provides additional information about the signal being digitized by the ADC.The user can configure the Subclasss 1 JESD204B-based high speed serialized output in a variety of one-lane, two-lane, four-lane, and eight-lane configurations, depending on the DDC configuration and the acceptable lane rate of the receiving logic device. Multidevice synchronization is supported through the SYSREF? and SYNCINB? input pins.The AD9689 has flexible power-down options that allow significant power savings when desired. All of these features can be programmed using a 3-wire serial port interface (SPI).The AD9689 is available in a Pb-free, 196-ball BGA, specified over the ?40?C to +85?C ambient temperature range. This product is protected by a U.S. patent.Note that throughout this data sheet, multifunction pins, such as FD_A/GPIO_A0, are referred to either by the entire pin name or by a single function of the pin, for example, FD_A, when only that function is relevant.Product Highlights Wide, input ?3 dB bandwidth of 9 GHz supports direct radio frequency (RF) sampling of signals up to about 5 GHz. Four integrated, wideband decimation filters and NCO blocks supporting multiband receivers. Fast NCO switching enabled through the GPIO pins. SPI controls various product features and functions to meet specific system requirements. Programmable fast overrange detection and signal monitoring. On-chip temperature diode for system thermal management. 12 mm ? 12 mm, 196-ball BGA. Pin, package, feature, and memory map compatible with the AD9208 14-bit, 3.0 GSPS, JESD204B dual ADC.Applications Diversity multiband and multimode digital receivers 3G/4G, TD-SCDMA, W-CDMA, and GSM, LTE, LTE-A Electronic test and measurement systems Phased array radar and electronic warfare DOCSIS 3.0 CMTS upstream receive paths HFC digital reverse path receivers

For a limited time, take a live test drive of the AD6676 by using our?remote evaluation software.The AD6676 is a highly integrated IF subsystem that candigitize radio frequency (RF) bands up to 160 MHz in widthcentered on an intermediate frequency (IF) of 70 MHz to 450 MHz. Unlike traditional Nyquist IF sampling ADCs, theAD6676 relies on a tunable band-pass ?-? ADC with a high oversampling ratio to eliminate the need for band specific IFSAW filters and gain stages, resulting in significant simplification of the wideband radio receiver architecture. On-chip quadraturedigital downconversion followed by selectable decimation filtersreduces the complex data rate to a manageable rate between 62.5 MSPS to 266.7 MSPS. The 16-bit complex output data is transferred to the host via a single or dual lane JESD204B interfacesupporting line rates of up to 5.333 Gbps.Applications Wideband cellular infrastructure equipment and repeaters? Point-to-point microwave equipment? Instrumentation? Spectrum and communication analyzers? Software defined radio
