LTC3630AEMSE Demo Board (MSOP) | 4V ≤ VIN ≤ 76V, VOUT = 1.8V/3.3V/5V/Adjustable @ 500mA
Analog Devices Inc.
Demonstration circuit 2105A is a 500mA output DC/DC power supply. There are two versions: DC2105A-A is a board featuring LTC3630A in the exposed pad MSOP-16 package, with 4V to 76V input range; DC2105A-B is a board featuring LTC3630, with 4V to 65V input range. The LTC3630A operates in a high efficiency Burst Mode® operation and includes internal high and low side switches. The board provides jumper selected output voltages of 1.8V, 3.3V, 5V and an option for additional voltages. LTC3630A has internal soft-start and a provision for increasing soft-start time.
$180.56 - $186.86
Distributors
Currency:
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
DigiKey | 505-DC2105A-A-ND | 1 | $178.44 | $178.44 | $178.44 | $178.44 | $178.44 | $178.44 | Buy | |
|
|
Analog Devices Inc | DC2105A-A | $180.56 | $180.56 | $180.56 | $180.56 | $180.56 | $180.56 | Buy | ||
|
 |
Arrow North American Components | DC2105A-A | 2 | 1 | $162.50 | $162.50 | $162.50 | $162.50 | $162.50 | $162.50 | Buy |
|
|
Mouser Electronics | 584-DC2105A-A | 0 | 1 | $186.86 | $186.86 | $186.86 | $186.86 | $186.86 | $186.86 | Buy |
|
|
Verical Marketplace | DC2105A-A | 2 | 1 | $162.50 | $162.50 | $162.50 | $162.50 | $162.50 | $162.50 | Buy |
