DAC8728SPAGR
Texas Instruments
Category: Data Converters
DAC 8-CH Resistor-String 16-bit 64-Pin TQFP T/R
$31.56 - $42.69
Distributors
Currency:
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
DigiKey | DAC8728SPAGR-ND | 0 | $31.56 | Buy | ||||||
|
 |
Arrow North American Components | DAC8728SPAGR | 0 | 1500 | $26.86 | Buy | |||||
|
 |
AVNET Europe | DAC8728SPAGR | 1500 | * $21.74 | Buy | ||||||
|
|
AVNET Express | DAC8728SPAGR | 1500 | $19.18 | Buy | ||||||
|
|
Mouser Electronics | 595-DAC8728SPAGR | 0 | 1500 | $31.54 | Buy | |||||
|
|
Newark | DAC8728SPAGR | 1500 | $25.19 | $25.19 | $25.19 | $25.19 | $25.19 | $18.10 | Buy | |
|
|
Texas Instruments | DAC8728SPAGR | 297 | 1 | $36.71 | $36.71 | $36.71 | $32.63 | $23.99 | $23.99 | Buy |
|
|
Win Source | DAC8728SPAGR | 78 | 1 | $32.47 | $29.41 | $29.41 | $29.41 | $29.41 | Buy |
Parts in family
Technical Specifications
| Lead Free Status | No |
| ROHS Compliance | Compliant |
| Approx. Price (US$) | 16.45 | 1ku |
| Code to Code Glitch(Typ)(nV-sec) | 4 |
| DAC | Channels |
| DAC Architecture | String |
| Gain Error(Max)(%FSR) | 0.01 |
| INL(Max)(+/-LSB) | 4 |
| Interface | Parallel |
| Internal Reference Drift(Max)(ppm/degC) | N/A |
| Offset Error(Max)(%) | N/A |
| Operating Temperature Range(C) | -40 to 105 |
| Output Range Max.(mA/V) | 33 |
| Output Range Min.(mA/V) | -16.5 |
| Output Type | Buffered Voltage |
| Package Group | QFN,TQFP |
| Package Size | mm2 |
| Power Consumption(Typ)(mW) | 107 |
| Priority | 1 |
| Rating | Catalog |
| Reference | Type |
| Resolution(Bits) | 16 |
| Sample / Update Rate(MSPS) | 0.066 |
| Settling Time(s) | 15 |
| Special Features | On-chip Offset and Gain Calibration |
| Zero Code Error(Typ)(mV) | 10 |
