LTM4650MPY
Analog Devices Inc.
Category: Power Management ICs
Dual 25A or Single 50A DC/DC Module Regulator Features: Dual 25A or Single 50A Output Input Voltage Range: 4.5V to 15V Output Voltage Range: 0.6V to 1.8V ±1.5% Maximum Total DC Output Error Over Line, Load and Temperature Differential Remote Sense Amplifier Current Mode Control/Fast Transient Response Adjustable Switching Frequency Frequency Synchronization Overcurrent Foldback Protection Multiphase Parallel Current Sharing with Multiple LTM4650s Up to 300A Internal Temperature Monitor Pin Compatible with the LTM4620 (Dual 13A, Single 26A) and LTM4630 (Dual 18A, Single 36A) Selectable Burst Mode® Operation Soft-Start/Voltage Tracking Output Overvoltage Protection 16mm × 16mm × 5.01mm BGA Package
$158.48 - $189.88
Distributors
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
DigiKey | LTM4650MPY-ND | 85 | $153.12 | $165.06 | $148.55 | $148.55 | $148.55 | $148.55 | Buy | |
|
|
Analog Devices Inc | LTM4650MPY | $189.88 | $183.75 | $183.75 | $183.75 | $183.75 | $183.75 | Buy | ||
|
|
Mouser Electronics | 584-LTM4650MPY | 7 | 1 | $158.48 | $158.48 | $158.48 | $158.48 | $158.48 | $158.48 | Buy |
|
|
Win Source | LTM4650MPY | 2700 | Buy |
Parts in family
Technical Specifications
| ROHS Compliance | Not Compliant |
