Analog Devices Inc.

Category: Switches and Multiplexers

The MAX4736 is a low on-resistance, low-voltage, dualsingle-pole/double throw (SPDT) analog switch thatoperates from a single 1.6V to 4.2V supply. This devicehas fast switching speeds (tON = 25ns, tOFF = 20nsmax), handles rail-to-rail analog signals, and consumesless than 4µW of quiescent power. The MAX4736 hasbreak-before-make switching.When powered from a 3V supply, the MAX4736 features low 0.6Ω on-resistance (RON), with 0.1Ω RONmatching and 0.05Ω RON flatness. The digital logic input is 1.8V CMOS compatible when using a single 3V supply.The MAX4736 has one normally open (NO) switch and one normally closed (NC) switch, and is available in 12-pin TQFN-EP (3mm x 3mm), QFN-EP (3mm x 3mm), 10-pin µMAX and 10 pin µDFN (2mm x 2mm) packages.ApplicationsAudio/Video Signal RoutingBattery-Powered ApplicationsCell PhonesCommunication SystemsHard DrivesLow-Voltage Data-Acquisition SystemsModemsPCMCIA CardsPower Routing

$2.26 - $5.46
