The AD8312 is a complete, low cost subsystem for the measurement of RF signals in the frequency range of 50 MHz to 3.5 GHz. It has a typical dynamic range of 45 dB and is intended for use in a wide variety of cellular handsets and other wireless devices. It provides a wider dynamic range and better accuracy than possible using discrete diode detectors. In particular, its temperature stability is excellent over the full operating range of ?40?C to +85?C.Its high sensitivity allows measurement at low power levels, thus reducing the amount of power that needs to be coupled to the detector. It is essentially a voltage-responding device, with a typical signal range of 1.25 mV to 224 mV rms or ?45 dBm to 0 dBm, referencing 50 ?.For convenience, the signal is internally ac-coupled, using a 5 pF capacitor to a load of 3 k? in shunt with 1.3 pF. This high-pass coupling, with a corner at approximately 16 MHz, determines the lowest operating frequency. Therefore, the source may be dc grounded.The AD8312 output, VOUT, increases from close to ground to about 1.2 V because the input signal level increases from 1.25 mV to 224 mV. A capacitor may be connected between the VOUT and CFLT pins when it is desirable to increase the time interval over which averaging of the input waveform occurs.The AD8312 is available in a 6-ball, 1.0 mm ? 1.5 mm, wafer-level chip scale package and consumes 4.2 mA from a 2.7 V to 5.5 V supply.Applications Cellular handsets (GSM, CDMA, WCDMA) RSSI and TSSI for wireless terminal devices Transmitter power measurement

The AD8337 is a low noise, single-ended, linear-in-dB, general-purpose variable gain amplifier (VGA) usable at frequencies from dc to 100 MHz; the ?3 dB bandwidth is 280 MHz. Excellent bandwidth uniformity across the entire gain range and low output-referred noise makes the AD8337 ideal for gain trim applications and for driving high speed analog-to-digital converters (ADCs).Excellent dc characteristics combined with high speed make the AD8337 particularly suited for industrial ultrasound, PET scanners, and video applications. Dual-supply operation enables gain control of negative-going pulses such as generated by photodiodes or photomultiplier tubes.The AD8337 uses the popular and versatile X-AMP? architecture, exclusively from Analog Devices, Inc., with a gain range of 24 dB. The gain control interface provides precise linear-in-dB scaling of 19.7 dB/V, referenced to VCOM.The AD8337 includes an uncommitted operational current-feedback preamplifier (PrA) that operates in inverting or noninverting configurations. Using external resistors, the device can be configured for gains of 6 dB or greater. The AD8337 is characterized by a noninverting PrA gain of 2? using two external 100 ? resistors. The attenuator has a range of 24 dB, and the output amplifier has a fixed gain of 8? (18.06 dB). The lowest nominal gain range is 0 dB to 24 dB and can be shifted up or down by adjusting the preamp gain. Multiple AD8337s can be connected in series for larger gain ranges, and for interstage filtering to suppress noise and distortion, and for nulling offset voltages.The operating temperature range is ?40?C to +85?C, and it is available in an 8-lead, 3 mm ? 3 mm LFCSP.Applications Gain trim PET scanners High performance AGC systems I/Q signal processing Video Industrial and medical ultrasound Radar receivers

The AD8338 is a variable gain amplifier (VGA) for applicationsthat require a fully differential signal path, low power, low noise,and a well-defined gain over frequency. Although the inputs aredifferential, the device can also be driven with a single-endedsource if required.The basic gain function is linear-in-dB and is controlled by thevoltage applied to Pin GAIN. The nominal gain range spansfrom 0 dB to 80 dB for control voltages between 0.1 V to 1.1 Vwith a slope of 12.5 mV/dB. The nominal gain range can beshifted up or down via direct access to Pin INPD and Pin INMD,the current inputs of the VGA. For example, driving the INPDand INMD pins with 50 ? resistors shifts the gain range up by20 dB, that is, 20 dB to 100 dB, and lowers the input referrednoise of the device to 1.5 nV/?Hz. Additionally, the gain slopecan be inverted via logic Pin MODE.The AD8338 includes additional circuit blocks to enable inputoffset correction and automatic gain control (AGC). DC offsetvoltages are removed by the offset correction circuit, whichbehaves like a high-pass filter whose corner is set with an externalcapacitor. The AGC function varies the gain of the AD8338 tomaintain a constant rms output voltage. An externally appliedvoltage to Pin VAGC with respect to the voltage at Pin VREFsets the output rms amplitude. A capacitor from Pin DETO toground sets the response time of the AGC circuit.The AD8338 offers additional versatility by providing access tothe internal summing nodes of the VGA core and the outputamplifiers. With the addition of a few external passive components,users can customize the gain, bandwidth, input impedance, andnoise profile of the device to fit their application.The AD8338 uses a single-supply voltage of 3.0 V to 5.0 V andis very power efficient, consuming as little as 3 mA quiescentcurrent at mid gain. The AD8338 is available in a 3 mm ? 3 mm,RoHS-compliant, 16-lead LFCSP and is specified over theindustrial temperature range of ?40?C to +85?C.APPLICATIONS Front end for inductive telemetry systems Ultrasonic signal receivers Signal compression for driving an ADC AGC amplifiers

The AD8372 is a dual, digitally controlled, variable gainamplifier (VGA) that provides precise gain control, high IP3,and low noise figure. The excellent distortion performance andmoderate signal bandwidth make the AD8372 a suitable gain control device for a variety of multichannel receiverapplications.For wide input dynamic range applications, the AD8372provides a broad 41 dB gain range. The gain is programmedthrough a bidirectional 4-pin serial interface. The serial interface consists of a clock, latch, data input, and data output linesfor each channel. The AD8372 provides the ability to set the transconductance of the output stage using a single external resistor. The RXT1 and RXT2 pins provide a band gap derived stable reference voltage of 1.56 V. Typically 2.0 k? shunt resistors to ground are used toset the maximum gain to a nominal value of 31 dB. The currentsetting resistors can be adjusted to manipulate the gain anddistortion performance of each channel. This is a flexible feature in applications where it is desirable to trade off distortion performance for lower power consumption.The AD8372 is powered on by applying the appropriate logiclevel to the ENB1, ENB2 pins. When powered down, the AD8372consumes less than 2.6 mA and offers excellent input-to-outputisolation. The gain setting is preserved when powered down.Fabricated on an Analog Devices, Inc., high frequency BiCMOS process, the AD8372 provides precise gain adjustment capabilities with good distortion performance. The quiescent current of theAD8372 is typically 106 mA per channel. The AD8372 amplifier comes in a compact, thermally enhanced 5 mm ? 5 mm 32-leadLFCSP package and operates over the temperature range of ?40?C to +85?C.Applications Differential ADC drivers CMTS upstream direct sampling receivers CATV modem signal scaling Generic RF/IF gain stages Single-ended-to-differential conversion

The AD8418 is a high voltage, high resolution current shunt amplifier. It features an initial gain of 20 V/V, with a maximum ?0.15% gain error over the entire temperature range. The buffered output voltage directly interfaces with any typical converter. The AD8418 offers excellent input common-mode rejection from ?2 V to +70 V. The AD8418 performs bidirectional current measurements across a shunt resistor in a variety of automotive and industrial applications, including motor control, battery management, and solenoid control.The AD8418 offers breakthrough performance throughout the ?40?C to +125?C temperature range. It features a zero drift core, which leads to a typical offset drift of 0.1 ?V/?C throughout the operating temperature range and the common-mode voltage range. The AD8418 is fully qualified for automotive applications and includes EMI filters and patented circuitry to enable output accuracy with pulse-width modulation (PWM) type input common-mode voltages. The typical input offset voltage is ?200 ?V. The AD8418 is offered in 8-lead MSOP and SOIC packages.Applications High-side current sensing in Motor controls Solenoid controls Power management Low-side current sensing Diagnostic protection

The LT1993-2 is a low distortion, low noise Differential Ampli?er/ADC driver for use in applications from DC to 800MHz. The LT1993-2 has been designed for ease of use, with minimal support circuitry required. Exceptionally low input-referred noise and low distortion products (with either single-ended or differential inputs) make the LT1993-2 an excellent solution for driving high speed 12-bit and 14-bit ADCs. In addition to the normal un? ltered outputs (+OUT and ?OUT), the LT1993-2 has a built-in 175MHz differential low pass ?lter and an additional pair of ?ltered outputs (+OUTFILTERED, ?OUTFILTERED) to reduce external ?ltering components when driving high speed ADCs. The output common mode voltage is easily set via the VOCM pin, eliminating either an output transformer or AC-coupling capacitors in many applications.The LT1993-2 is designed to meet the demanding requirements of communications transceiver applications. It can be used as a differential ADC driver, a general-purpose differential gain block, or in any other application requiring differential drive. The LT1993-2 can be used in data acquisition systems required to function at frequencies down to DC.The LT1993-2 operates on a 5V supply and consumes 100mA. It comes in a compact 16-lead 3 ? 3 QFN package and operates over a ?40?C to 85?C temperature range.Applications Differential ADC Driver for: Imaging Communications Differential Driver/Receiver Single Ended to Differential Conversion Differential to Single Ended Conversion Level Shifting IF Sampling Receivers SAW Filter Interfacing/Buffering

DC1699A-A: Demo Board for the LT6108 High Side Current Sense Amplifier with Reference and Comparator.

The LTC6432-15 is an ultra-high dynamic range differentialgain block amplifier designed to drive high resolution,high speed ADCs. It offers a full GHz of data bandwidt h forcomplex spectrally efficient modulations schemes or wh ereresistance to blockers is critical. This unique device cansimultaneously achieve low noise, incomparable linearity and flat gain over the 100kHz to 1GHz band.Unlike wideband GaAs PHEMTs, MESFETs and GaN FETs, this SiGe based amplifier exhibits low 1/f noise and can be used down to 100kHz.The LTC6432-15 is designed for ease of use requiring a minimum of support components. Impedance matching, temperature compensation and bias control are handled internally to ensure consistent performance over environmental changes.All A-Grade LTC6432-15 devices are tested and guaranteed for OIP3 at 150MHz. The LTC6432-15 is housed in a 4mm ? 4mm, 24L, QFN package with an exposed pad for thermal management and low inductance. For a single-ended 50? IF Gain Block with similar performance, see the related LTC6433-15.Applications Differential 1GHz Bandwidth ADC Driver Wideband Test Instrument Amplifier Differential IF Amplifier 50?/75? Balanced IF Amplifier

The LTC6560 is a low-noise, transimpedance amplifier (TIA) with 220MHz bandwidth. The LTC6560?s low noise, high transimpedance and low power dissipation are ideal for LIDAR receivers using avalanche photodiodes (APDs). The LTC6560 features 74k? transimpedance gain and 30?A linear input current range. Using an input circuit with a total input capacitance of 2pF, the input current noise density is 4.8pA/?Hz at 200MHz. With lower capacitance, noise and bandwidth improve further. The LTC6560 operates from a single 5V supply and consumes only 90mW. Utilizing the LTC6560?s output MUX, multiple LTC6560 devices can be combined to a single output. The LTC6560?s fast overload recovery and fast output MUXing make it well suited for LIDAR receivers with multiple APDs. Its single-ended output can swing 2VP-P on a 100? load. Its low impedance op amp style output has been designed to drive back-terminated 50? cables.The LTC6560 is packaged in a compact 3mm ? 3mm 16-pin leadless QFN package with an exposed pad for thermal management and low inductance.Applications LIDAR Receiver Industrial Imaging

The LTC2063/LTC2064/LTC2065 are single, dual, and quad low power, zero-drift, 20kHz amplifiers. The LTC2063/LTC2064/LTC2065 enable high resolution measurement at extremely low power levels.Typical supply current is 1.4?A per amplifier with a maximum of 2?A. The available shutdown mode has been optimized to minimize power consumption in duty-cycled applications and features low charge loss during power-up, reducing total system power.The LTC2063/LTC2064/LTC2065?s self-calibrating circuitry results in very low input offset (5?V max) and offset drift (0.02?V/?C). The maximum input bias current is only 20pA and does not exceed 100pA over the full specified temperature range. The extremely low input bias current of the LTC2063/LTC2064/LTC2065 allows the use of high value power-saving resistors in the feedback network.With its ultralow quiescent current and outstanding precision, the LTC2063/LTC2064/LTC2065 can serve as a signal chain building block in portable, energy harvesting and wireless sensor applications.The LTC2063 is available in 6-lead SC70 and 5-lead TSOT-23 packages. The LTC2064 is available in 8-lead MSOP and 10-lead DFN packages. The LTC2065 is available in 14-lead TSSOP and 16-lead 3mm ? 3mm QFN packages. These devices are fully specified over the ?40?C to 85?C and ?40?C to 125?C temperature ranges.Applications Signal Conditioning in Wireless Mesh Networks Portable Instrumentation Systems Low-Power Sensor Conditioning Gas Detection Temperature Measurement Medical Instrumentation Energy Harvesting Applications Low Power Current Sensing
