The AD9888 is a complete 8-bit, 170 MSPS, monolithic analog interface optimized for capturing RGB graphics signals from personal computers and workstations. Its 170 MSPS encode rate capability and full-power analog bandwidth of 500 MHz supports resolutions of up to 1600 × 1200 (UXGA) at 75 Hz.For ease of design and to minimize cost, the AD9888 is a fully integrated interface solution for flat panel displays. The AD9888 includes an analog interface that has a 170 MHz triple ADC with an internal 1.25 V reference phase-locked loop (PLL) to generate a pixel clock from HSYNC and COAST; midscale clamping; and programmable gain, offset, and clamp controls. The user provides only a 3.3 V power supply, analog input, and HSYNC and COAST signals. Three-state CMOS outputs can be powered from 2.5 V to 3.3 V.The on-chip PLL of the AD9888 generates a pixel clock from the HSYNC and COAST inputs. Pixel clock output frequencies range from 10 MHz to 170 MHz. PLL clock jitter is typically less than 450 ps p-p at 170 MSPS. When the COAST signal is presented, the PLL maintains its output frequency in the absence of HSYNC. A sampling phase adjustment is provided. Data, HSYNC, and clock output phase relationships are maintained. The PLL can be disabled, and an external clock input can be provided as the pixel clock. The AD9888 also offers full sync processing for composite sync and sync-on-green applications.A CLAMP signal is generated internally or can be provided by the user through the CLAMP input pin. This device is fully programmable via a 2-wire serial port.Fabricated in an advanced CMOS process, the AD9888 is provided in a space-saving, 128-lead, MQFP, surface-mount, plastic package and is specified over the 0°C to 70°C temperature range. The AD9888 is also available in a Pb-free package. APPLICATIONS RGB Graphics Processing LCD Monitors and Projectors Plasma Display Panels Scan Converters Microdisplays Digital TV

DLP 0.33 1080p DMD 92-CLGA

TPS65132B Dual Output LCD Bias for Smartphones Evaluation Module

DLP® LightCrafter™ Display 2000 Evaluation Module

DLP® LightCrafter™ 4500

IC FLUORESCENT LAMP DRIVER 20V DIP-18; No. of Digits:-; No. of Segments:-; Driver Case Style:DIP; No. of Pins:18; Supply Voltage Min:4.5V; Supply Voltage Max:20V; Interface Type:-; Operating Temperature Min:0 C; Packaging:Each ;RoHS Compliant: Yes

Display Port Redriver 56-Pin WQFN EP T/R

RESONANT LAMP BALLAST CONTROLLER

SN75DP122A DisplayPort 1:2 Switch with Integrated TMDS Translator

IN STOCK SHIP TODAY
