The ADA4430-1 is a fully integrated video reconstruction filter that combines excellent video specifications with low power consumption and an ultralow power disable, making it ideal for portable video filtering applications. With 1 dB frequency flatness out to 8 MHz and 50 dB rejection at 27 MHz, the ADA4430-1 is ideal in SD video applications including NTSC and PAL.The ADA4430-1 operates on single supplies as low as 2.5 V and as high as 6 V while providing the dynamic range required by the most demanding video systems.The ADA4430-1 also provides an on-chip dc offset to avoid clipping of the sync tips at the filter output, as well as SAG correction that permits smaller capacitor values to be used in applications with ac-coupled outputs.The ADA4430-1 is available in a 6-lead SC70 package and is rated to work in the extended automotive temperature range of -40°C to +125°C.

The ADG2128 is an analog cross point switch with an array size of 8 × 12. The switch array is arranged so that there are eight columns by 12 rows, for a total of 96 switch channels. The array is bidirectional, and the rows and columns can be configured as either inputs or outputs. Each of the 96 switches can be addressed and configured through the I2C compatible interface. Standard, full speed, and high speed (3.4 MHz) I2C interfaces are supported. Any simultaneous switch combination is allowed. An additional feature of the ADG2128 is that switches can be updated simultaneously, using the LDSW command. In addition, a RESET option allows all of the switch channels to be reset/off. At power-on, all switches are in the off condition. The device is packaged in a 32-lead, 5 mm × 5 mm LFCSP_VQ.APPLICATIONS AV switching in TV Automotive infotainment AV receivers CCTV Ultrasound applications KVM switching Telecom applications Test equipment/instrumentation PBX systems

The ADT74701 controller is a multichannel temperature sensor and PWM fan controller and fan speed monitor for systems requiring active cooling. It is designed to interface directly to an I2C® bus. The ADT7470 can monitor up to 10 daisy-chained TMP05 temperature sensors. It can also monitor and control the speed of four fans, in automatic or in manual control loops.A FULL_SPEED input is provided to allow the fans to be blasted to maximum speed, via external hardware control, under extreme thermal conditions or on system startup. An SMBALERT interrupt communicates error conditions such as fan under speed and over temperature measurements to the system service processor. Individual error conditions can then be read from status registers over the I2C bus.APPLICATIONS Servers Networking and telecommunications equipment Desktops

The ADuC831 is a fully integrated 247 kSPS data acquisitionsystem incorporating a high performance self-calibrating multi-channel12-bit ADC, dual 12-bit DACs, and programmable8-bit MCU on a single chip.The microcontroller core is an 8052, and therefore 8051-instruction-set compatible with 12 core clock periods per machinecycle. 62 kBytes of nonvolatile Flash/EE program memory areprovided on-chip. Four kBytes of nonvolatile Flash/EE datamemory, 256 bytes RAM and 2 kBytes of extended RAM arealso integrated on-chip.The ADuC831 also incorporates additional analog functionalitywith two 12-bit DACs, power supply monitor, and a band gapreference. On-chip digital peripherals include two 16-bit Σ-∆DACs, dual output 16-bit PWM, watchdog timer, time intervalcounter, three timers/counters, Timer 3 for baud rate generationand serial I/O ports (I2C, SPI and UART).On-chip factory firmware supports in-circuit serial download anddebug modes (via UART), as well as single-pin emulation modevia the EA pin. The ADuC831 is supported by QuickStart™ andQuickStart Plus development systems featuring low cost softwareand hardware development tools. The part is specified for 3 V and 5 V operation over the extendedindustrial temperature range, and is available in a 52-lead plasticquad flatpack package and in a 56-lead chip scale package.Applications Optical networking—laser power control Base station systems Precision instrumentation, smart sensors Transient capture systems DAS and communications systems

The ADuM250N/ADuM251N/ADuM252N are 5-channel digital isolators based on Analog Devices, Inc., iCoupler® technology. Combining high speed, complementary metal-oxide semiconductor (CMOS) and monolithic air core transformer technology, these isolation components provide outstanding performance characteristics superior to alternatives such as optocoupler devices and other integrated couplers. The maximum propagation delay is 13 ns with a pulse width distortion of less than 4.5 ns at 5 V operation. Channel to channel matching of propagation delay is tight at 4.0 ns maximum.The ADuM250N/ADuM251N/ADuM252N data channels are independent and are available in a variety of configurations with a withstand voltage rating of 5.0 kV rms (see the Ordering Guide). The devices operate with the supply voltage on either side ranging from 1.7 V to 5.5 V, providing compatibility with lower voltage systems as well as enabling voltage translation functionality across the isolation barrier.Unlike other optocoupler alternatives, dc correctness is ensured in the absence of input logic transitions. Two different fail-safe options are available by which the outputs transition to a predetermined state when the input power supply is not applied.Applications General-purpose multichannel isolation Serial peripheral interface (SPI)/data converter isolation Industrial field bus isolation

The AD52521 is a dual-channel, I2C, nonvolatile memory,digitally controlled potentiometer with 256 positions. These devices perform the same electronic adjustmentfunctions as mechanical potentiometers, trimmers, andvariable resistors. The parts’ versatile programmability allowsmultiple modes of operation, including read/write access in theRDAC and EEMEM registers, increment/decrement of resistance,resistance changes in ±6 dB scales, wiper setting readback,and extra EEMEM for storing user-defined information, such asmemory data for other components, look-up table, or systemidentification information.The AD5251/AD5252 allow the host I2C controllers to writeany of the 64-/256-step wiper settings in the RDAC registersand store them in the EEMEM. Once the settings are stored,they are restored automatically to the RDAC registers at systempower-on; the settings can also be restored dynamically.The AD5251/AD5252 provide additional increment,decrement, +6 dB step change, and –6 dB step change insynchronous or asynchronous channel update mode. Theincrement and decrement functions allow stepwise linearadjustments, with a ± 6 dB step change equivalent to doublingor halving the RDAC wiper setting. These functions are usefulfor steep-slope, nonlinear adjustments, such as white LEDbrightness and audio volume control.The AD5251/AD5252 have a patented resistance-tolerancestoring function that allows the user to access the EEMEM andobtain the absolute end-to-end resistance values of the RDACsfor precision applications.The AD5251/AD5252 are available in TSSOP-14 packages.AD5251 has only 50 kΩ resistance options and AD5252 isavailable in 1 kΩ, 10 kΩ, 50 kΩ, and 100 kΩ options. All partsare guaranteed to operate over the –40°C to +105°C extendedindustrial temperature range.APPLICATIONS Mechanical potentiometer replacement General-purpose DAC replacement LCD panel VCOM adjustment White LED brightness adjustment RF base station power amp bias control Programmable gain and offset control Programmable voltage-to-current conversion Programmable power supply Sensor calibrations1 Protected by U.S. Patent 7,688,240.

The AD5253 / AD5254 are quad-channel, I2C, nonvolatile memory, digitally controlled potentiometers with 64/256 positions, respectively. These devices perform the same electronic adjustment functions as mechanical potentiometers, trimmers, and variable resistors.The parts’ versatile programmability allows multiple modes of operation, including read/write access in the RDAC and EEMEM registers, increment/decrement of resistance, resistance changes in ±6 dB scales, wiper setting readback, and extra EEMEM for storing user-defined information, such as memory data for other components, look-up table, or system identification information.The AD5253 / AD5254 allow the host I2C controllers to write any of the 64-/256-step wiper settings in the RDAC registers and store them in the EEMEM. Once the settings are stored, they are restored automatically to the RDAC registers at system power-on; the settings can also be restored dynamically.The AD5253 / AD5254 provide additional increment, decrement, +6 dB step change, and –6 dB step change in synchronous or asynchronous channel update mode. The increment and decrement functions allow stepwise linear adjustments, with a ± 6 dB step change equivalent to doubling or halving the RDAC wiper setting. These functions are useful for steep-slope, nonlinear adjustments, such as white LED brightness and audio volume control.The AD5253 / AD5254 have a patented resistance-tolerance storing function that allows the user to access the EEMEM and obtain the absolute end-to-end resistance values of the RDACs for precision applications.The AD5253 / AD5254 are available in TSSOP-20 packages in 1 kΩ, 10 kΩ, 50 kΩ, and 100 kΩ options. All parts are guaranteed to operate over the –40°C to +105°C extended industrial temperature range. In this data sheet, the nonvolatile memory and EEMEM terms are used interchangeably, as are the digital potentiometer and RDAC terms.APPLICATIONS Mechanical potentiometer replacement Low resolution DAC replacement RGB LED backlight control White LED brightness adjustment RF base station power amp bias control Programmable gain and offset control Programmable attenuators Programmable voltage-to-current conversion Programmable power supply Programmable filters Sensor calibrations

The AD5290 is one of the few high voltage, high performance, and compact digital potentiometers1 in the market at present. This device can be used as a programmable resistor or resistor divider. The AD5290 performs the same electronic adjustment function as mechanical potentiometers, variable resistors, and trimmers, with enhanced resolution, solid-state reliability, and superior temperature stability.With digital rather than manual control, the AD5290 provides layout flexibility and allows closed-loop dynamic controllability.The AD5290 is available in MSOP-10 package and has 10 kΩ, 50 kΩ, and 100 kΩ options. All parts are guaranteed to operate over the –40°C to +125°C extended automotive temperature range.Applications High voltage DAC Programmable power supply Programmable gain and offset adjustment Programmable filters and delays Actuator control Audio volume control Mechanical potentiometer replacement1 The RDAC segmentation is protected by U.S. Patent Number 5,495,245.

The AD725 is a very low cost general purpose RGB to NTSC/PAL encoder that converts red, green and blue color componentsignals into their corresponding luminance (basebandamplitude) and chrominance (subcarrier amplitude and phase)signals in accordance with either NTSC or PAL standards.These two outputs are also combined on-chip to provide acomposite video output. All three outputs are available separatelyat voltages of twice the standard signal levels as requiredfor driving 75 Ω, reverse-terminated cables.An evaluation board is available for this product and may be ordered using the following product number: AD725-EB.

The ADuM1100 is a digital isolator based on Analog Devices Inc., iCoupler® technology. Combining high speed CMOS and monolithic air core transformer technology, this isolation component provides outstanding performance characteristics superior to alternatives, such as optocoupler devices.Configured as a pin-compatible replacement for existing high speed optocouplers, the ADuM1100 supports data rates as high as 25 Mbps and 100 Mbps.The ADuM1100 operates with a voltage supply ranging from 3.0 V to 5.5 V, boasts a propagation delay of <18 ns and edge asymmetry of <2 ns, and is compatible with temperatures up to 125°C. It operates at very low power, less than 0.9 mA of quiescent current (sum of both sides), and a dynamic current of less than 160 μA per Mbps of data rate. Unlike other optocoupler alternatives, the ADuM1100 provides dc correctness with a patented refresh feature that continuously updates the output signal.The ADuM1100 is offered in three grades. The ADuM1100AR and ADuM1100BR can operate up to a maximum temperature of 105°C and support data rates up to 25 Mbps and 100 Mbps, respectively. The ADuM1100UR can operate up to a maximum temperature of 125°C and supports data rates up to 100 Mbps.APPLICATIONS Digital field bus isolation Opto-isolator replacement Computer-peripheral interface Microprocessor system interface General instrumentation and data acquisition applications
