GPS Development Tools STEVAL-STRKT01 LoRa IoT tracker

Audio IC Development Tools Microphone coupon board based on the MP23AB01DH fully differential analog MEMS microphone

D/A Converter, 2 Func, PDSO8

Audio Codec Stereo 2 2 -40 C 85 C 48 kSPS ;RoHS Compliant: Yes

4 ADC with PLL, 192 kHz, 24-Bit ADC

1024-Position, 1% Resistor Tolerance Error, SPI Interface and 50-TP Memory Digital Rheostat Features: Single-channel, 1024-/256-position resolution 20 kΩ, 50 kΩ and 100 kΩ nominal resistance Maximum ±1% nominal resistor tolerance error 50-times programmable (50-TP) wiper memory Rheostat mode temperature coefficient: 5 ppm/°C 2.7 V to 5.5 V single-supply operation ±2.5 V to ±2.75 V dual-supply operation for ac or bipolar operations SPI-compatible interface Wiper setting readback Power on refreshed from 50-TP memory Thin LFCSP, 10-lead, 3 mm × 3 mm × 0.8 mm package Compact MSOP, 10-lead, 3 mm × 4.9 mm × 1.1 mm package

SigmaDSP Multichannel 28-Bit Audio Processor Features: 16-channel digital audio processor Accepts sample rates up to 192 kHz 28-bit × 28-bit multiplier with full 56-bit accumulator Fully programmable program RAM for custom program download Parameter RAM allows complete control of 1,024 parameters Control port features safeload for transparent parameter updates and complete mode and memory transfer control Target/slew RAM for click-free volume control and dynamic parameter updates See data sheet for additional features

+30 V/15 V Operation 128-Position Digital Potentiometer Features: 128 positions  10 kΩ, 50 kΩ, 100 kΩ  20 V to 30 V single-supply operation ±10 V to ±15 V dual-supply operation 3-wire SPI®-compatible serial interface  THD 0.006% typical  Programmable preset  Power shutdown: less than 1 μA  iCMOS™ process technology

CLHW, WAFER SAWN FFC NDP NO MARK CONDUCTIVE, WAFER ROHS COMPLIANT: YES

CLHW, WAFER SAWN FFC NDP NO MARK CONDUCTIVE, WAFER ROHS COMPLIANT: YES
