| Price | $2.02 | $7.65 | $1.92 | $2.25 | $3.43 | ||||||
| RoHS | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | |
| Lead Status | No | No | No | No | No | No | No | No | No | No | |
| ADC | Slope | ADC12 - 8ch | ADC12 - 8ch | ADC10 - 5ch | SigmaDelta16 - 1ch | ADC10 - 12ch | SigmaDelta16 - 3ch | SigmaDelta16 - 3ch | ADC10 - 6ch,SigmaDelta24 - 3ch | ||
| Multiplier | N/A | 16x16 | N/A | N/A | N/A | N/A | 32x32 | 32x32 | 32x32 | ||
| Timers - 32-bit | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ||
| Timers - 16-bit | 1 | 2 | 2 | 1 | 2 | 2 | 2 | 2 | 4 | ||
| Frequency(MHz) | 8 | 8 | 8 | 8 | 8 | 16 | 16 | 16 | 25 | ||
| Operating Temperature Range(C) | -40 to 85 | -40 to 85 | -40 to 85 | -40 to 85 | -40 to 85 | -40 to 105,-40 to 85 | -40 to 85 | -40 to 85 | -40 to 85 | ||
| Rating | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | ||
| UART | 0 | 2 | 1 | 0 | 1 | 1 | 2 | 2 | 3 | ||
| Active Power (uA/MHz) | 200 | 280 | 280 | 200 | 262 | 270 | 280 | 280 | 346 | ||
| GPIO Pins(#) | 48 | 48 | 48 | 14 | 48 | 32 | 72 | 72 | 72 | ||
| AES | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | ||
| Min VCC | 1.8 | 1.8 | 1.8 | 1.8 | 1.8 | 1.8 | 1.8 | 1.8 | 1.8 | ||
| Package Group | LQFP,VQFN | LQFP,TQFP,VQFN | LQFP,TQFP,VQFN | SOIC,TSSOP,VQFN | BGA MICROSTAR JUNIOR,LQFP | DSBGA,TSSOP,VQFN | LQFP | LQFP | LQFP | ||
| Package Size | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | ||
| Approx. Price (US$) | 1.35 | 1ku | 4.75 | 1ku | 3.35 | 1ku | 1.70 | 1ku | 6.20 | 1ku | 2.00 | 1ku | 4.00 | 1ku | 4.30 | 1ku | 2.75 | 1ku | ||
| Max VCC | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | ||
| DMA | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 3 | ||
| Non-volatile Memory (KB) | 8 | 60 | 16 | 4 | 60 | 32 | 48 | 60 | 64 | ||
| Comparators(Inputs) | Yes | Yes | Yes | 0 | Yes | 0 | Yes | Yes | 0 | ||
| Standby Power (LPM3-uA) | 0.7 | 1.6 | 1.6 | 0.7 | 1.1 | 0.7 | 1.1 | 1.1 | 2.9 | ||
| SPI | 0 | 2 | 1 | 0 | 2 | 1 | 2 | 2 | 4 | ||
| Wakeup Time (us) | 6 | 6 | 6 | 6 | 6 | 1 | 6 | 6 | 3 | ||
| Special I/O | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | ||
| Additional Features | LCD,Watchdog,Brown Out Reset | Watchdog,Temp Sensor | Watchdog,Temp Sensor | Watchdog,Temp Sensor,Brown Out Reset | LCD,Real-Time Clock,Watchdog,DAC,OpAmp,Temp Sensor,Brown Out Reset | Watchdog,Temp Sensor,Brown Out Reset | LCD,Watchdog,Temp Sensor,Brown Out Reset | LCD,Watchdog,Temp Sensor,Brown Out Reset | LCD,Real-Time Clock,Watchdog,Temp Sensor,Brown Out Reset,IrDA | ||
| BSL | UART | UART | UART | UART | UART | UART | UART | UART | UART | ||
| RAM(KB) | 0.25 | 2 | 0.5 | 0.25 | 2 | 1 | 2 | 2.5 | 4 | ||
| I2C | 0 | 0 | 0 | 0 | 1 | 1 | 2 | 2 | 1 | ||
| CPU | MSP430 | MSP430 | MSP430 | MSP430 | MSP430 | MSP430 | MSP430 | MSP430 | MSP430 |
