Dual-core SHARC+ and ARM Cortex-A5 SOC, dual DDR, 2xEthernet, 2xUSB, SDIO, PCIe, 529-cspBGA Features: 500 MHz (3.0 GFLOPS) per core 5Mbits/640KB L1 memory/core with parity Optional cache/SRAM mode 32-bit, 40-bit & 64-bit floating point supportARM Core Infrastructure: 500 MHz ARM Cortex-A5 (with Neon/FPU) 32kByte/32kByte L1 Instr./Data Cache 256kByte L2 CacheShared System Memory 256KB L2 SRAM with ECC protectionUp to Two High Speed Memory Controllers DDR3-900, DDR2-800 & LPDDR (16-bit)Advanced Hardware Accelerators FFT/iFFT (20 GFLOPS, 5usec per 1K-pt FFT) FIR/IIR and SINC Filters, ASRC Security Crypto Engines with OTPPackaging 19mm x 19mm BGA  (0.8mm pitch) Commercial, Industrial & Automotive 2x Ethernet MAC One Gigabit (RGMII) and one 10/100 (RMII) With IEEE-1588 & AVB support (QoS & clock recovery) 2x USB2.0 HS OTG/Device Controllers (MAC/PHY) 2x CAN2.0 SD/SDIO/MMC/eMMC (with SDXC support) PCIe2.0 (1 lane) (SC589 only) Up to 8 Full SPORT interfaces (w/ TDM & I2S modes) S/PDIF Tx/Rx, 8x ASRC pairs, PCG  2x Dual-SPI and 1x QuadSPI (w/ direct  execution) 3x I2C and 3x UARTs (w/ Flow Control) Enhanced Parallel Peripheral Interface For video I/O or parallel converter interface 2x Link Ports (bi-directional, 8-bit, up to 150MB/sec) 3x Enhanced PWM,  ADC Control Module (ACM) 8x GP Timer, 1x GP Counter, WDT and RTC Up to 102 GPIO (mux’ed w/ other interfaces) 8-ch 12-bit 1MSPS Housekeeping ADC Thermal Sensor

Configurable Impedance Network Analyzer & Potentiostat with Integrated Cortex M3 Core Features: Analog performance 160 kSPS, 16-bit, precision analog-to-digital converter (ADC) 4 dedicated voltage measurement channels 8 current measurement channels Impedance measurement engine High precision voltage reference Supply noise rejection filtering Ultralow leakage configurable switch matrix 12-bit digital-to-analog converter (DAC) Precision instrumentation amplifier control loop 6-channel CapTouch controller Temperature sensor Analog hardware accelerators Autonomous analog front-end (AFE) controller Independent sequencer for AFE functions Direct digital synthesizer (DDS)/arbitrary waveform generator Receive filters Complex impedance measurement (DFT) engine Processing 16 MHz ARM Cortex-M3 processor 384 kB of embedded flash memory 32 kB system SRAM 16 kB Flash configured EEPROM Integrated full-speed USB 2.0 controller and PHY Multilayer advanced microcontroller bus architecture (AMBA) bus matrix Central direct memory access (DMA) controller Real-time clock (RTC) General-purpose, wake-up, and watchdog timers Communication Input/output I2S and beeper interface LCD display controller (parallel and serial) LCD segment controller SPI, I2C, and UART peripheral interfaces Programmable GPIOs Power Coin cell battery compatible 2.5 V to 3.6 V active measurement range Power management unit (PMU) Power-on reset (POR) and power supply monitor (PSM) Packages and temperature range Operating temperature range: −40°C to +85°C Package: 120-lead, 8 mm × 8 mm CSP_BGA

ANALOG DEVELOPMENT KIT ACCESSORIES;

DEBUGGERS, EMULATORS & JTAG TOOLS;

DIGITAL SIGNAL PROCESSOR, 16-BIT SIZE, 16-EXT BIT, 100MHZ, CMOS, PBGA144

The ADL5391 draws on three decades of experience in advanced analog multiplier products. It provides the same general mathematical function that has been field proven to provide an exceptional degree of versatility in function synthesis:VW = α × (VX x VY)/1 V + VZThe most significant advance in the ADL5391 is the use of anew multiplier core architecture, which differs markedly fromthe conventional form that has been in use since 1970. Theconventional structure that employs a current mode, translinearcore is fundamentally asymmetric with respect to the X and Yinputs, leading to relative amplitude and timing misalignmentsthat are problematic at high frequencies. The new multiplier coreeliminates these misalignments by offering symmetric signalpaths for both X and Y inputs. The Z input allows a signal to beadded directly to the output. This can be used to cancel a carrieror to apply a static offset voltage.The fully differential X, Y, and Z input interfaces are operationalover a ±2 V range, and they can be used in single-ended fashion.The user can apply a common mode at these inputs to varyfrom the internally set VPOS/2 down to ground. If these inputsare ac-coupled, their nominal voltage will be VPOS/2. These inputinterfaces each present a differential 500 Ω input impedance up toapproximately 700 MHz, decreasing to 50 Ω at 2 GHz. The gainscaling input, GADJ, can be used for fine adjustment of the gainscaling constant (α) about unity.The differential output can swing ±2 V about the VPOS/2common-mode and can be taken in a single-ended fashion aswell. The output common mode is designed to interface directlyto the inputs of another ADL5391. Light dc loads can be groundreferenced; however, ac-coupling of the outputs is recommendedfor heavy loads.The ENBL pin allows the ADL5391 to be disabled quickly to astandby mode. It operates off supply voltages from 4.5 V to 5.5 Vwhile consuming approximately 130 mA.The ADL5391 is fabricated on Analog Devices, Inc. proprietary,high performance, 65 GHz, SOI complementary, SiGe bipolarIC process. It is available in a 16-lead, RoHS compliant, LFCSPand operates over a −40°C to +85°C temperature range.Evaluation boards are available.Applications Wideband multiplication and summing High frequency analog modulation Adaptive antennas (diversity/phased array) Square-law detectors and true rms detectors Accurate polynomial function synthesis DC capable VGA with very fast control

The Blackfin® Processor family has been expanded to address the need for embedded Controller Area Network (CAN) connectivity. This connectivity is powerful when utilized in conjunction with the high performance 16-/32-bit Blackfin embedded processor core,the flexible cache architecture, the enhanced DMA subsystem, and the Dynamic Power Management (DPM) functionality. System designers can take advantage of the combined control and signal processing capabilities of the processor core across a wide range of end applications.The ADSP-BF534 is a functional extension of the popularADSP-BF531 / ADSP-BF532 / ADSP-BF533 processors and is ideally suited for a variety of CAN networked applications. The ADSP-BF534 offers a high performance series for embedded applications such as automotive safety, automotive body control, automotive driver assistance, automotive entertainment, and industrial factory automation. This processor is ideally suited for a broad range of industrial, instrumentation, and medicalapplications that allow for scalability and CAN network connectivity that utilize a mix of control, plus signal processing in the end product for robust systems

The Blackfin® Processor family has been expanded to address the need for embedded Controller Area Network (CAN) connectivity. This connectivity is powerful when utilized in conjunction with the high performance 16-/32-bit Blackfin embedded processor core,the flexible cache architecture, the enhanced DMA subsystem, and the Dynamic Power Management (DPM) functionality. System designers can take advantage of the combined control and signal processing capabilities of the processor core across a wide range of end applications.The ADSP-BF534 is a functional extension of the popularADSP-BF531 / ADSP-BF532 / ADSP-BF533 processors and is ideally suited for a variety of CAN networked applications. The ADSP-BF534 offers a high performance series for embedded applications such as automotive safety, automotive body control, automotive driver assistance, automotive entertainment, and industrial factory automation. This processor is ideally suited for a broad range of industrial, instrumentation, and medicalapplications that allow for scalability and CAN network connectivity that utilize a mix of control, plus signal processing in the end product for robust systems

The Blackfin® Processor family has been expanded to address the ever-increasing need for pervasive embedded network connectivity. This connectivity is powerful when utilized in conjunction with the high performance 16-/32-bit Blackfin embedded processor core, the flexible cache architecture, the enhanced DMA subsystem, and the Dynamic Power Management (DPM) functionality. System designers can take advantage of the combined control and signal processing capabilities of the processor core across a wide range of end applications through the scalability of the pin and code compatibility of these new family members. The ADSP-BF536 and ADSP-BF537 are a functional extension of the popular ADSP-BF531 / ADSP-BF532 / ADSP-BF533 processors, and they are ideally suited for a variety of networked applications. The ADSP-BF537 is the higher performance series member, with more embedded memory enabling higher throughput needs for embedded applications suchas video security/surveillance and industrial-environment-based distributed control/factory automation applications. The ADSP-BF536 offers exceptional performance and is designed for low cost connected devices such as remote monitoring devices, VoIP, point-of-sale terminals, and biometrics/security applications. Both devices are ideally suited for a broadrange of industrial, instrumentation, medical, and consumer appliance applications— allowing for scalability based upon the required network bandwidth and mix of control, plus signal processing needed in the end product.

The ADSP-21584 processor is part of the new, high-performance, power-efficient, real-time series that delivers greater than 24 giga-floating-point operations per second using two enhanced SHARC+® cores and advanced DSP accelerators (FFT, FIR, IIR). The ADSP-SC58x and ADSP-2158x series consume less than 2 watts, making the new processor line-up more than 5x more power efficient than previous SHARC products. This advantage provides industry leading digital signal processing performance for applications where thermal management sets the limit for power consumption, or where the higher costs and lower reliability of fans cannot be tolerated.  Applications include automotive, consumer and professional audio, multi-axis motor control, and energy distribution systems.The ADSP-2158x family is designed for applications where a DSP co-processor is exclusively needed and includes two SHARC+ cores and a peripheral set matched to a DSP core.  The new, code-compatible, enhanced SHARC+ core features clock-rate and power-efficiency improvements and adds instruction/data cache options, native double-precision floating-point support, and a number of other new instructions. Designed for low-power and using a low-leakage CMOS process, the ADSP-SC58x/2158x families deliver 500 MHz with 105°C environments in mind and provide a roadmap to future implementations at higher performance. More than 1.5 Mbytes of fast on-chip SRAM and a DDR3/2/LP interface aid efficient real-time performance while the memory subsystem includes major enhancements with advanced DMA engines for simultaneous data transfer.With software IP protection a growing industry security concern, ARM® TrustZone® security and an onboard crypto hardware accelerators are included. For applications where reliability is a critical requirement, memory parity and error-correction hardware provide higher data integrity. The overall integration and low-power features offered by the new ADSP-SC58x and ADSP-2158x series deliver significant BOM and board area savings and provide lower design complexity and reduced time to market for today’s complex applications.The ADSP-SC58x/2158x  is supported by ADI’s award winning Crosscore®  Embedded Studio development tool suite, providing design engineers with interactive, real-time development tools that help optimize their design and speed time to market.Additionally, ADI and Micrium have collaborated to offer µC/OS-II® & µC/OS-III® real-time kernels on SHARC+.The compatible ADSP-SC584 EZ-KIT-Lite development board and ICE-1000/2000 emulators facilitate the creation, test, and debug of advanced applications. Working in tandem with CrossCore Embedded Studio, the emulators provide state-of-the-art support for all JTAG-compliant Analog Devices processors now utilizing CoreSight™ from ARM.
