OPT3002 SENSOR EVALUATION BOARD

Photo IC Sensors Ultra-Low Noise Integr Intensity Sensor

OPT3001 digital ambient light sensor (ALS) with high-precision human-eye response evaluation module

Image Sensors 780 X 488-Pixel CCD Image Sensor

TISOPT3002DNPR

Time-of-Flight Sensor 56-Pin COG T/R

Automotive Digital Ambient Light Sensor (ALS) With High-Precision Human-Eye Response 6-USON -40 to 105

High-speed high-precision digital ambient light sensor (ALS) 8-SOT-5X3 -40 to 85

Features for the OPT4001:

• High precision, high speed light-to-digital conversion over high speed I2C interface in two package variants
• Precision optical filtering to closely match human eye with excellent near infrared (IR) rejection
• Semi-logarithmic output with 9 binary logarithmic full-scale light range and highly linear response within each range
• Built-in automatic full-scale light range selection logic, which switches measurement range based on input light condition with excellent gain matching between ranges
• 28 bits of effective dynamic range from
  • 312.5 µlux to 83 klux for PicoStar™ package variant
  • 437.5 µlux to 117 klux for SOT-5x3 package variant
• 12 configurable conversion times from 600 µs to 800 ms is an excellent choice for a wide variety of high speed and high precision applications
• External pin interrupt for hardware synchronized trigger and interrupts (only on SOT-5X3 package variant)
• Internal FIFO for output registers with I2C burst readout
• Low operating current: 30 µAwith ultra-low power standby: 2 µA
• Operating temperature range: –40°C to +85°C
• Wide power-supply range: 1.6 V to 3.6 V
• 5.5 V Tolerant I/O pins
• Selectable I2C address
• Small-form factor
  • PicoStar™ package: 0.84 mm x 1.05 mm x 0.226 mm
  • SOT-5X3: 2.1mm x 1.9mm x 0.6mm

Infrared (IR) BoosterPack Plug-in Module

The EVAL-ADPD1080Z-PRX evaluation kit provides users with a simple means of connecting with the ADPD1080 hardware, collecting data from the ADPD1080, and evaluating long range proximity capabilities. The ADPD1080 hardware is configured with a large area, p-type, intrinsic, n-type (PIN) semiconductor photodiode as a proximity sensor. In this configuration, motion and proximity in front of the EVAL-ADPD1080Z-PRX are measured by detecting the amount of infrared (IR) light reflected off of objects and the change in IR light as objects move relative to the EVAL-ADPD1080Z-PRX. The evaluation kit requires the EVAL-ADPDM3Z and the Applications Wavetool, which can be downloaded from the EVAL-ADPD1080Z-PRX product page. The Applications Wavetool is a graphical user interface (GUI) that provides users with low level and high level configurability, real-time data analysis, and user datagram protocol (UDP) transfer capabilities so that the evaluation board can easily connect to a PC. The USB port of the PC powers the EVAL-ADPDM3Z and the EVAL-ADPD1080Z-PRX. On-board voltage regulators provide voltage supplies for the ADPD1080. The evaluation board schematic indicates signal names for easy identification. Full specifications for the ADPD1080 are available in the ADPD1080 data sheet. Refer to both this data sheet and the EVAL-ADPD1080Z-PRX user guide when working with the evaluation board.
