Lithium-Ion Battery Pulse Chargers with Overcurrent Protection Features: Complete Pulse Charger for 1-Cell Lithium-Ion Batteries Sense Resistor Limits Maximum Current for Safety 1% Float Voltage Accuracy End-of-Charge (C/10) Detection Output Programmable Charge Termination Timer Internal 0.35 NMOS Switch No Blocking Diode Required SEL Pin to Set Either 4.1V or 4.2V/Cell (LTC1730-4) Low-Battery Drain (1µA Max) when Input Supply Is Removed Battery Temperature Sensing and Charge Qualification Automatic Trickle Charge for Low-Battery Cell Automatic Battery Refresh

Monolithic Linear Lithium-Ion Battery Charger with Thermal Regulation Features: Complete Linear Charger for 1-Cell Lithium-Ion Batteries Thermal Regulation Maximizes Charging Rate without Risk of Overheating* No External MOSFET, Sense Resistor or Blocking Diode Required Up to 1.5A Charging Current Preset Charge Voltage with 1% Accuracy Programmable Charge Current with 7% Accuracy Programmable Charge Termination Timer Tiny Thermally Enhanced 10-Pin MSOP Package Charge Current Monitor Useful for Gas Gauging* C/10 Charge Current Detection Output Automatic Recharge Thermistor Input for Temperature Qualified Charging AC Present Logic Output 4.1V/4.2V Pin Selectable Output Voltage

Lithium-Ion Linear Battery Charger in ThinSOT Features: Low Profile (1mm) ThinSOT™ No Blocking Diode Required No Sense Resistor Required 1% Accurate Preset Voltages: 4.1V or 4.2V Charge Current Monitor Output for Charge Termination Programmable Charge Current: 200mA to 700mA Automatic Sleep Mode with Input Supply Removal Manual Shutdown Negligible Battery Drain Current in Shutdown Undervoltage Lockout Self Protection for Overcurrent/Overtemperature

Lithium-Ion Linear Battery Charger in ThinSOT Features: Low Profile (1mm) ThinSOT™ No Blocking Diode Required No Sense Resistor Required 1% Accurate Preset Voltages: 4.1V or 4.2V Charge Current Monitor Output for Charge Termination Programmable Charge Current: 200mA to 700mA Automatic Sleep Mode with Input Supply Removal Manual Shutdown Negligible Battery Drain Current in Shutdown Undervoltage Lockout Self Protection for Overcurrent/Overtemperature

Li-Ion Battery Charger Termination Controllers Features: Built-In Termination: 3-Hour Time-Out C/10 Detection with Status Indicator Trickle Charge Preconditioning If Cell <2.7V Charging Enabled When 0°C < T < 50°C Automatic Charger Present Detection Automatic Battery Present Detection 1- or 2-Cell, 4.1V/Cell or 4.2V/Cell Options Precision Internal 0.2% Voltage Feedback Divider Compatible with LT1505/LT1510/LT1511/LT1512/LT1513/LT1769 Small Footprint/Low Profile

Isolated DC/DC Converters DC-DC, PCB Mount, Input 18-36VDC, Output 3.3V 14A, 46W

USB Power Manager in ThinSOT Features: Manages Total Power Between a USB Peripheral and Battery Charger Minimal Voltage Drop (100mV at 500mA) Ultralow Battery Drain: 1µA Reverse Current Blocking Diode not Required Undervoltage Lockout Very Few External Components Compatible with Several LTC Linear Battery Chargers Overtemperature Protected Dual Battery Charge Priority Management Low Profile (1mm) SOT-23 Package

High Voltage High Current Controller for Battery Charging and Power Management Features:Complete High Performance Battery Charger When Paired with a DC/DC ConverterWide Input and Output Voltage Range: 3V to 60VInput Ideal Diode for Low Loss Reverse Blocking and Load SharingOutput Ideal Diode for Low Loss PowerPath™ and Load Sharing with the BatteryInstant-On Operation with Heavily Discharged BatteryProgrammable Input and Charge Current: ±1% Accuracy±0.25% Accurate Programmable Float VoltageProgrammable C/X or Timer Based Charge TerminationNTC Input for Temperature Qualified Charging28-Lead 4mm × 5mm QFN or SSOP Packages

High Voltage High Current Controller for Battery Charging and Power Management Features:Complete High Performance Battery Charger When Paired with a DC/DC ConverterWide Input and Output Voltage Range: 3V to 60VInput Ideal Diode for Low Loss Reverse Blocking and Load SharingOutput Ideal Diode for Low Loss PowerPath™ and Load Sharing with the BatteryInstant-On Operation with Heavily Discharged BatteryProgrammable Input and Charge Current: ±1% Accuracy±0.25% Accurate Programmable Float VoltageProgrammable C/X or Timer Based Charge TerminationNTC Input for Temperature Qualified Charging28-Lead 4mm × 5mm QFN or SSOP Packages

High Voltage High Current Controller for Battery Charging with Maximum Power Point Control Features:Maximum Power Control: Solar Panel Input CompatibleComplete High Performance Battery Charger When Paired with a DC/DC ConverterWide Input and Output Voltage Range: 3V to 60VInput Ideal Diode for Low Loss Reverse Blocking and Load SharingOutput Ideal Diode for Low Loss PowerPath™ and Load Sharing with the BatteryProgrammable Charge Current: ±1% Accuracy±0.25% Accurate Programmable Float VoltageProgrammable C/X or Timer Based Charge TerminationNTC Input for Temperature Qualified Charging28-Lead 4mm × 5mm QFN or SSOP Packages
