	TE Connectivity KUP-14D45-24	TE Connectivity KUP-14D11F-24	TE Connectivity R10-R2X2-V700	TE Connectivity KUP-14A45F-120	TE Connectivity T9CP5A54-120	TE Connectivity SSRK-600A20	TE Connectivity RT444024F	Crydom DC60S5-B	Omron G6JU-2FS-Y-TR DC5	TE Connectivity EV200HDANA
Price
RoHS								Compliant	Compliant
Lead Status								No
Contact Material	AgCdO	Ag	AgCdO	AgCdO	AgSnOlnO		AgNi90/10
Terminal Type	Solder	Plug-In	PCB-THT	Solder	Quick Connect		Plug-In
Contact Current Class	5 – 10	5 – 10	5 – 10	5 – 10	20 – 30		5 – 10
Product Length	1.55	1.55	.949	1.55	50.3		29
Coil Special Features	Electrical Indicator	UL Coil Insulation Class B	Sensitive Version	Electrical Indicator	UL Coil Insulation Class F		UL Coil Insulation Class F
Contact Limiting Breaking Current	10	5	5	10	30		8
Contact Voltage Rating	240	240	120	240	277		250
Power Relay Type	Industrial Panel Plug-In	Industrial Panel Plug-In	Industrial Panel Plug-In	Industrial Panel Plug-In	Standard	Solid State	Standard
Product Weight	2.988	2.988	40	2.988		9.87	13
Width Class (Mechanical)	30 – 40	30 – 40	16 – 20	30 – 40	25 – 30		12 – 16
Insulation Initial Dielectric Between Adjacent Contacts	2200	2200	1000	2200			2500
Insulation Initial Resistance	100	100	10000	100	1000
Environmental Category of Protection	RTI	RTI	RTIII	RTI	RTII		RTII
Product Height	1.97	1.97	30.2	1.97	27.9		.618
Height Class (Mechanical)	40 – 50	40 – 50	30 – 40	40 – 50	20 – 35		15 – 16
Contact Limiting Short-Time Current	10	5	5	10	30
Coil Magnetic System	Monostable, DC	Monostable, DC	Monostable, DC	Monostable, AC	Monostable, AC		Monostable, DC
Insulation Initial Dielectric Between Contacts & Coil	2200	1200	1000	2200	2500	4000	5000
Product Width	35.7	35.7	.736	35.7	27.4		12.7
Length Class (Mechanical)	35 – 40	35 – 40	20 – 25	35 – 40	50 – 55		25 – 30
Contact Limiting Making Current	10	5	5	10	30		15
Contact Switching Load (Min)	300mA @ 12V	300mA @ 12V	300mA @ 12V	300mA @ 12V	1000mA @ 5V
Actuating System	DC	DC	DC	AC
Relay Mounting Type	Socket	Socket	Printed Circuit Board	Socket	Quick Connect	DIN Rail	Socket
Environmental Ambient Temperature (Max)	70	70	167	113	70		185
Contact Current Rating (Max)	10	10	5	10	30		8
Contact Number of Poles	3	3	2	3	2		2
Contact Limiting Continuous Current	10	5	5	10	30		8
Packaging Method	Package	Package	Package	Package	Tray/Box		Carton
Coil Resistance	472	472	700	1700	2800		1440
Coil Voltage Rating	24	24	24	120	120		24			32 – 95
Environmental Ambient Temperature Class	50 – 70	50 – 70	70 – 85	0 – 50	-40 – 70
Operating Temperature Range	-45 – 70	-45 – 70	-55 – 75	-45 – 45		-30 – 80
Contact Arrangement	3 Form C (CO)	3 Form C (CO)	2 Form C (CO)	3 Form C (CO)	1 Form C (CO)	1 Form A (SPST-NO)	2 Form A (NO)			1 Form X, SPST-NO
Insulation Initial Dielectric Between Open Contacts	1200	1200	500	1200	1500		1000
Insulation Initial Dielectric Between Coil & Contact Class	1500 – 2500	1500 – 2500	500 – 1000	1500 – 2500	1500 – 2500		4000 – 5000
Coil Power Rating DC	1250	1250	900				400
Coil Power Rating Class	1000 – 1500	1000 – 1500	800 – 1000	2 – 3			300 – 400
Contact Plating Material		Gold
Coil Power Rating AC				2.9	1600
Insulation Clearance Between Contact & Coil					3.18		.394
Insulation Creepage Between Contact & Coil					.25		.394
Relay Termination Type					.25 x .032 Quick Connect Terminals	Finger-Safe (IP20) Screw Clamps
Insulation Clearance Class					2.5 – 4		8
Insulation Creepage Class					5.5 – 8		8
Insulation Special Features					6000V Initial Surge Withstand Voltage between Contacts & Coil		Tracking Index of Relay Base PTI250
Contact Switching Voltage (Max)					277		400			900
Output Type						AC
Output Current (Min)						.15
Housing Style						DIN Mount with Integral Heatsink
Output Voltage (Max)						660
R-Switch & slimSSR Relays						Yes
Switch Arrangement						1 Form A (SPST-NO)
Input Voltage Typical						90
Input Voltage						90 – 280
Case Color						Black
Output Switching						Zero
Coupling						Optical
Dimensions (L x W x H) (Approximate)						82.3 x 22.5 x 111.5
Output Current Rating						.15 – 20
Output Voltage Rating (AC Relays)						48 – 660
Auxiliary Contacts										With
Economizer										With
Termination Style										Stud Terminals
High Voltage Connection (Power)										Stud Terminals
Power Switching										Yes
Product Type										Relay
Contact Current Rating										500
Contact Base Material										Copper (Cu)
Voltage (Max)										3920
RF Rated										No
Mounting Type										Bottom
Relay Type										High Voltage
High Voltage Connection (Coil)										Flying Leads
