CSD86330Q3D

Texas Instruments CSD86330Q3D

CSD87334Q3DT

Texas Instruments CSD87334Q3DT

CSD87350Q5D

Texas Instruments CSD87350Q5D

CSD87351Q5D

Texas Instruments CSD87351Q5D

DS2003CM

Texas Instruments DS2003CM

CSD87381PT

Texas Instruments CSD87381PT

ULN2004ADE4

Texas Instruments ULN2004ADE4

CSD15380F3

Texas Instruments CSD15380F3

CSD17551Q5A

Texas Instruments CSD17551Q5A

CSD18502KCS

Texas Instruments CSD18502KCS

Price
RoHS Compliant Compliant Compliant Compliant No Compliant Compliant Compliant Compliant Yes
Lead Status No No No No No No No No No Yes
ID, Continuous Drain Current at Ta=25degC(A) 20 20 40 32 15 0.5 13.5
Configuration PowerBlock PowerBlock PowerBlock PowerBlock PowerBlock Single Single Single
Ploss Current(A) 15 12 25 20 8
Operating Temperature Range(C) -55 to 150 -55 to 150 -55 to 150 -55 to 150 -55 to 150
VDS(V) 25 30 30 30 30 20 30 40
Power Loss(W) 1.9 1.6 3 2.5 1
VGS(V) 10 10 10 10 10 10 20 20
Approx. Price (US$) 0.70 | 1ku 0.55 | 1ku 0.95 | 1ku 0.79 | 1ku 0.23 | 1ku 0.30 | 1ku 0.05 | 1ku 0.28 | 1ku 0.81 | 1ku
Package (mm) SON3x3 PowerBlock SON3x3 PowerBlock SON5x6 PowerBlock SON5x6 PowerBlock 3x2.5 LGA LGA0.6x0.7 SON5x6 TO-220
Package Group SOIC
Peak Output Current(mA) 350
Delay Time(Typ)(ns) 1000
Rating Catalog Catalog Catalog Catalog
Switching Voltage(Max)(V) 50
Vol@Lowest Spec Current(Typ)(mV) 900
Package Size mm2
Output Voltage(Max)(V) 50
Iout/ch(Max)(mA) 500
Iout_off(Typ)(uA) 20
Drivers Per Package 7
RDS(on) Typ at VGS=2.5V(Typ)(mOhm) 2220
QGD Typ(nC) 0.027 1.4 8.4
RDS(on) Typ at VGS=4.5V(mOhm) 1170 9 3.3
QG Typ(nC) 0.216 6 52
Logic Level Yes Yes Yes
IDM, Max Pulsed Drain Current(Max)(A) 1.6 85 400
VGSTH Typ(V) 1.10 1.7 1.8
Rds(on) Max at VGS=4.5V(mOhms) 1460 11 4.3
Rds(on) Max at VGS=10V(mOhms) 8.8 2.9
ID, Package limited(A) 48 100
ID, Silicon limited at Tc=25degC(A) 212
