18 GHz to 44 GHz, GaAs, pHEMT, MMIC, 1/2 W Power Amplifier Features: Output P1dB: 29 dBm PSAT: 29.5 dBm Gain: 23.5 dB Output IP3: 38 dBm Supply voltage: 5 V at 800 mA Integrated power detector 50 Ω matched input/output Die size: 2.750 mm × 1.805 mm × 0.102 mm

+3/+5 Volt Serial-Input Micropower 12-Bit DAC Features: Micropower - 100 µA Single Supply - 2.7 V to 5.5 V Operation Compact 1.75 mm Height SO-8 Package and 1.1 mm Height TSSOP-8 Package AD7390 - 12-Bit Resolution AD7391 - 10-Bit Resolution SPI and QSPI Serial Interface Compatible with Schmitt Trigger Inputs

Dual 1MSPS, 12-Bit, 2-Channel SAR ADC with Serial Interface Features: Dual 12-Bit, 2-Channel ADC Fast Throughput Rate 1 MSPS Specified for VDD of 2.7 V to 5.25 V Low Power: 11.4 mW Max at 1 MSPS with 3 V Supplies 24 mW Max at 1 MSPS with 5 V Supplies Wide Input Bandwidth 70 dB SNR at 300 kHz Input Frequency Onboard Reference 2.5 V Flexible Power/Throughput Rate Management Simultaneous Conversion/Read No Pipeline Delays High-Speed Serial Interface SPI®/QSPI™/ MICROWIRE™/DSP Compatible Shut-Down Mode: µA Max 20-Lead TSSOP Package

10 MHz, G = 1, 10, 100, 1000 iCMOS Programmable Gain Instrumentation Amplifier Features: Small package: 10-lead MSOP Programmable gains: 1, 10, 100, 1000 Digital or pin-programmable gain setting Wide supply: ±5 V to ±15 V Excellent dc performance High CMRR: 100 dB (minimum), G = 100 Low gain drift: 10 ppm/°C (maximum) Low offset drift: 1.2 µV/°C (maximum), G = 1000 See data sheet for additional features

Digitally Programmable Sensor Signal Amplifier with EMI Filters Features: EMI filters at input pins Specified from −40°C to +140°C Low offset voltage: 10 μV maximum Low input offset voltage drift: 65 nV/°C maximum High CMRR: 94 dB minimum Digitally programmable gain and output offset voltage Programmable output clamp voltage Open and short wire fault detection Low-pass filtering Single-wire serial interface Stable with any capacitive load SOIC_N and LFCSP_VQ packages 4.5 V to 5.5 V operation

Precision, Rail-to-Rail Input Current Sense Amplifier Features: Very Wide, Over-the-Top®, Input Common Mode Range   - Extends 44V Above V – (Independent of V +)   - Extends –0.3V Below V – Wide Power Supply Range: 2.85V to 36V Input Offset Voltage: 300µV Maximum Gain Accuracy: 1% Max Gain Congurable with External Resistors Operating Current: 150µA Slew Rate: 2V/µs Sense Input Current When Powered Down: 1nA Full-Scale Output Current: 1mA Minimum Operating Temperature Range –40°C to 125°C Available in 2mm × 3mm DFN and 8-Lead MSOP Packages

Complete Isolated RS485/RS422 Module Transceiver + Power Features: RS485/RS422 Transceiver: 2500VRMS for 1 Minute UL-CSA Recognized File #E151738 CSA Component Acceptance Notice 5A Isolated DC Power: 5V at Up to 200mA No External Components Required 20Mbps or Low EMI 250kbps Data Rate High ESD: ±15kV HBM on Transceiver Interface High Common Mode Transient Immunity: 30kV/μs Integrated Selectable 120Ω Termination 3.3V (LTM2881-3) or 5.0V (LTM2881-5) Operation 1.62V to 5.5V Logic Supply Pin for Flexible Digital Interface Maximum Continuous Working Voltage: 560VPEAK High Input Impedance Failsafe RS485 Receiver Current Limited Drivers and Thermal Shutdown Compatible with TIA/EIA-485-A and PROFIBUS High Impedance Output During Internal Fault Condition Low Current Shutdown Mode (< 10μA) General Purpose CMOS Isolated Channel 15mm × 11.25mm BGA and LGA Packages

Ultralow Noise, 150 mA CMOS Linear Regulator Features: Chinese data sheet available Ultralow noise: 9 μV rms, independent of VOUT No additional noise bypass capacitor required Stable with 1 μF ceramic input and output capacitors Maximum output current: 150 mA Input voltage range: 2.2 V to 5.5 V Low quiescent current IGND = 10 μA with zero load Low shutdown current: <1 μA Low dropout voltage: 105 mV at 150 mA load Initial output voltage accuracy: ±1% Up to 14 fixed output voltage options: 1.8 V to 3.3 V PSRR performance of 70 dB at 10 kHz Current limit and thermal overload protection Logic-controlled enable 5-lead TSOT package 4-ball, 0.8 mm × 0.8 mm, 0.4 mm pitch WLCSP AEC-Q100 qualified for automotive applications

300 mA, Low Dropout CMOS Linear Regulator Features: Maximum output current: 300 mA Input voltage range: 2.5 V to 5.5 V Light load efficient IGND = 75 μA with 100 μA load Low shutdown current: <1 μA Very low dropout voltage: 170 mV @ 300 mA load Initial accuracy: ±1% Accuracy over line, load, and temperature: ±2% 16 fixed output voltage options with tracking: 0.75 V to 3.3 V Low output noise: 40 μV rms High PSRR: 72 dB @ 1 kHz Stable with small 2.2 μF ceramic output capacitor See data sheet for additional features

Hot-Swappable Dual I2C Isolators, 5 kV Features: Bidirectional I2C communication Open-drain interfaces Suitable for hot swap applications 30 mA current sink capability 1000 KHz operation 3.0 V to 5.5 V supply/logic levels 16-lead SOIC wide body package version (RW-16) High temperature operation: 105°C 16-lead SOIC wide body enhanced creepage version (RI-16-2 Safety and regulatory approvals UL recognition: 5000 V rms for 1 minute per UL 1577 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (RI-16-2 package)
