| Price | $0.72 | $1.00 | $1.41 | ||||||||
| RoHS | Yes | Yes | Yes | Compliant | No | Compliant | Compliant | Compliant | Yes | No | |
| Lead Status | Yes | Yes | Yes | No | No | No | No | No | Yes | No | |
| Temp Coeff(Typ)(ppm/ degree C) | 20 | 20 | 15 | 15 | 15 | 15 | 15 | 15 | 15 | 14 | |
| Reference Voltage | Fixed | Fixed | Fixed | Fixed | Fixed | Adjustable,Fixed | Fixed | Fixed | Fixed | ||
| Operating Temperature Range(C) | -40 to 85 | -40 to 125,-40 to 85 | -40 to 125,-40 to 85 | -40 to 125,-40 to 85 | -40 to 125,-40 to 85 | -40 to 125,-40 to 85 | -40 to 85 | ||||
| Min Iz for Regulation(uA) | 50 | 65 | 60,60,62,68,74,91,100 | 60,60,62,68,74,91,100 | 60,60,62,68,74,91,100 | 60 | 60,60,68,74,91,100 | 60,60,68,74,91,100 | 60,60,68,74,91,100 | ||
| Rating | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | |
| Approx. Price (US$) | 0.27 | 1ku | 0.27 | 1ku | 0.22 | 1ku | 0.22 | 1ku | 0.22 | 1ku | 0.23 | 1ku | 0.70 | 1ku | 0.70 | 1ku | 0.70 | 1ku | 0.70 | 1ku | |
| Temp Coeff(Max)(ppm/ degree C) | 100 | 100 | 100,150 | 100,150 | 100,150 | 100,150 | 50 | 50 | 50 | 50 | |
| Iout/Iz(Max)(mA) | 25 | 25 | 15 | 15 | 15 | 12 | 15 | 15 | 15 | 5 | |
| Package Group | SC70,SOT-23,TO-92 | SC70,SOT-23,TO-92 | SC70,SOT-23,TO-92 | SC70,SOT-23,TO-92 | SC70,SOT-23,TO-92 | SC70,SOT-23,TO-92 | SOT-23 | SOT-23 | SOT-23 | SOT-23 | |
| VO(V) | 4.096 | 5 | 2.048,2.5,3,4.096,5,8.192,10 | 2.048,2.5,3,4.096,5,8.192,10 | 2.048,2.5,3,4.096,5,8.192,10 | 1.225 | 2.048,2.5,4.096,5,8.192,10 | 2.048,2.5,4.096,5,8.192,10 | 2.048,2.5,4.096,5,8.192,10 | 1.8,2.048,2.5,3,3.3,4.096,5 | |
| Pin/Package | 3SOT-23, 3TO-92, 5SC70 | 3SOT-23, 3TO-92, 5SC70 | 3SOT-23, 3TO-92, 5SC70 | 3SOT-23, 3TO-92, 5SC70 | 3SOT-23, 3TO-92, 5SC70 | 3SOT-23, 3TO-92, 5SC70 | 3SOT-23 | 3SOT-23 | 3SOT-23 | 5SOT-23 | |
| Package Size | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | |
| VO Adj(Min)(V) | 4.096 | 5 | 2.048 | 2.048 | 2.048 | 1.24 | 2.048 | 2.048 | 2.048 | ||
| Initial Accuracy(Max)(%) | 0.5 | 0.5 | 0.1,0.2,0.5,1,2 | 0.1,0.2,0.5,1,2 | 0.1,0.2,0.5,1,2 | 0.1,0.2,0.5,1,2 | 0.1,0.2,0.5 | 0.1,0.2,0.5 | 0.1,0.2,0.5 | 0.2,0.5 | |
| VO Adj(Max)(V) | 4.096 | 5 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | ||
| WBN 10-10 kHz(Typ)(uVrms) | 35 | 35 | 35 | 20 | 34 | 34 | 34 | 36 | |||
| Special Features | Enable pin | ||||||||||
| Vin(Max)(V) | 12 | ||||||||||
| LFN 0.1-10Hz(Typ)(Vpp) | 20 | ||||||||||
| Iq(Max)(uA) | 275 | ||||||||||
| Shutdown Current(Typ)(uA) | 2 | ||||||||||
| Vin(Min)(V) | 2 | ||||||||||
| Iq(Typ)(uA) | 160 |
