5.6 GHz to 8.6 GHz, GaAs, MMIC, I/Q Downconverter Features: Conversion gain: 13 dB typical Image rejection: 32 dBc typical Input P1dB compression: −6 dBm typical Input IP3: 3 dBm typical, 6.0 GHz to 8.6 GHz Noise figure: 2 dB typical LO to RF isolation: 48 dBm typical LO to IF isolation: 13 dBm typical RF to IF isolation: 10 dBm typical Amplitude balance: 0.2 dB typical Phase balance: −2° typical RF return loss: 10 dB typical LO return loss: 15 dB typical IF return loss: 15 dB typical Exposed paddle, 4 mm × 4 mm, 24-lead, LFCSP

5.6 GHz to 8.6 GHz, GaAs, MMIC, I/Q Downconverter Features: Conversion gain: 13 dB typical Image rejection: 32 dBc typical Input P1dB compression: −6 dBm typical Input IP3: 3 dBm typical, 6.0 GHz to 8.6 GHz Noise figure: 2 dB typical LO to RF isolation: 48 dBm typical LO to IF isolation: 13 dBm typical RF to IF isolation: 10 dBm typical Amplitude balance: 0.2 dB typical Phase balance: −2° typical RF return loss: 10 dB typical LO return loss: 15 dB typical IF return loss: 15 dB typical Exposed paddle, 4 mm × 4 mm, 24-lead, LFCSP

Precision 10V Reference Features: Pin Compatible with LH0070 and AD581 Ultralow Drift—5ppm/°C Max Slope Trimmed Output Voltage Operates in Series or Shunt Mode Output Sinks and Sources in Series Mode Very Low Noise < 1ppmP-P 0.1Hz to 10Hz > 100dB Ripple Rejection Minimum Input Voltage of 11V

High Performance, Multiphase Energy, and Power Quality Measurement IC Features: 7 high performance ADCs 101 dB SNR Wide input voltage range: ±1 V, 707 mV rms FS at gain = 1 Differential inputs ±25 ppm/°C maximum channel drift (including ADC, internal VREF, PGA drift) enabling 10000:1 dynamic input range Class 0.2 metrology with standard external components Power quality measurements Enables implementation of IEC 61000-4-30 Class S VRMS ½, IRMS ½ rms voltage refreshed each half cycle 10 cycle rms/12 cycle rms Dip and swell monitors Line frequency—one per phase Zero crossing, zero-crossing timeout Phase angle measurements Supports CTs and Rogowski coil (di/dt) sensors Multiple range phase/gain compensation for CTs Digital integrator for Rogowski coils Flexible waveform buffer Able to resample waveform to ensure 128 points per line cycle for ease of external harmonic analysis Events, such as dip and swell, can trigger waveform storage Simplifies data collection for IEC 61000-4-7 harmonic analysis Advanced metrology feature set Total and fundamental active power, volt amperes reactive (VAR), volt amperes (VA), watthour, VAR hour, and VA hour Total and fundamental IRMS, VRMS Total harmonic distortion Power factor Supports active energy standards: IEC 62053-21 and IEC 62053-22; EN50470-3; OIML R46; and ANSI C12.20 Supports reactive energy standards: IEC 62053-23, IEC 62053-24 High speed communication port: 20 MHz serial port interface (SPI) Integrated temperature sensor with 12-bit successive approximation register (SAR) ADC ±3°C accuracy from −40°C to +85°C

16-Bit, Isolated, Sigma-Delta ADC Features: 5 MHz to 21 MHz master clock input frequency Offset drift vs. temperature: ±0.6 μV/°C maximum SNR: 86 dB typical 16 bits, no missing codes Full-scale analog input voltage range: ±320 mV ENOB: 14 bits typical IDD1: 10 mA maximum On-board digital isolator Operating temperature range −40°C to +125°C (16-lead SOIC_W) −40°C to +105°C (8-lead SOIC_IC) 20 V operation on VDD1 High CMTI: 150 kV/μs minimum, VDD2 = 3.3 V Wide-body SOICs 16-lead SOIC_W 8-lead SOIC_IC with increased creepage Safety and regulatory approvals UL recognition 5700 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (Pending) VDE Certificate of Conformity DIN V VDE V 0884-10: VIORM = 1270 VPEAK DIN V VDE V 0884-11: VIORM = 1060 VPEAK (Pending)

High Voltage, Latch-Up Proof, 16-Channel Multiplexer Features: Latch-up proof 3.5 pF off source capacitance 64 pF off drain capacitance 0.35 pC typical charge injection ±0.02 nA on channel leakage Low on resistance: 155 typical ±9 V to ±22 V dual-supply operation 9 V to 40 V single-supply operation VSS to VDD analog signal range Human body model (HBM) ESD rating - 8 kV all other pins

Dual Channel, 16-Bit, 33 MUPS, Multispan, Multi-IO SPI DAC Features: 16-bit resolution 33 MUPS single channel rate in fast mode 22 MUPS single channel rate in precision mode 65 ns small signal settling time to 0.1% accuracy 100ns large signal settling time to 0.1% accuracy Ultra small glitch: < 50 pV×s Ultra low latency: 5 ns THD: −105 dB at 1 kHz Highly configurable output voltage span and offset 1.2 V and 1.8 V logic level compatible Single (classic), dual, and quad SPI modes Multiple error detectors, both analog and digital domains 2.5 V internal voltage reference, 10 ppm/°C maximum temperature coefficient 5 mm × 5 mm LFCSP

18-Bit, 2 MSPS/1 MSPS/500 kSPS, Precision, Pseudo Differential, SAR ADCs Features: Easy Drive Greatly reduced input kickback Input current reduced to 0.5 μA/MSPS Enhanced acquisition phase, ≥79% of cycle time at 1 MSPS First conversion accurate, no latency or pipeline delay Input span compression for single-supply operation Fast conversion allows low SPI clock rates Input overvoltage clamp protection sinks up to 50 mA SPI-/QSPI-/MICROWIRE-/DSP-compatible serial interface High performance Pseudo differential analog input range 0 V to VREF with VREF from 2.4 V to 5.1 V Throughput: 2 MSPS/1 MSPS/500 kSPS options INL: ±3.2 LSB maximum Guaranteed 18-bit, no missing codes SNR: 95 dB at fIN = 1 kHz at VREF = 5 V THD: −125 dB at fIN = 1 kHz, −108 dB at fIN = 100 kHz SINAD: 84.5 dB at fIN = 1 MHz (see Figure 17 in data sheet) Oversampled dynamic range 98 dB for OSR = 2 125 dB for OSR = 1024 Low power Single 1.8 V supply operation with 1.71 V to 5.5 V logic interface 2.5 mW at 500 kSPS (VDD only) 70 μW at 10 kSPS, 14 mW at 2 MSPS (total power) 10-lead packages: 3 mm × 3 mm LFCSP, 3 mm × 4.90 mm MSOP Pin compatible with AD4003/AD4007/AD4011 family Guaranteed operation: −40°C to +125°C

Single Supply, 24-Bit, Sigma-Delta ADC with 10 V and 0 mA to 20 mA Inputs Features: Internal or external clock Tested for robustness per: IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, CISPR 11 24-bit ADC with integrated analog front end Fast and flexible output rate: 1.25 SPS to 31.25 kSPS Channel scan data rate of 6.21 kSPS per channel (161 μs settling) 16 noise free bits at 1 kSPS per channel 85 dB rejection of 50 Hz and 60 Hz at 20 SPS per channel ±10 V inputs, 4 differential or 8 single-ended Pin absolute maximum rating ±50 V Absolute input pin voltage up to ±20 V ≥1 MΩ impedance ±0.06% accuracy at 25°C 0 mA to 20 mA inputs, 4 single-ended Pin absolute maximum rating ±50 mA Input range from −0.5 mA to +24 mA 60 Ω impedance ±0.08% accuracy at 25°C On-chip 2.5 V reference ±0.12% accuracy at 25°C, ±5 ppm/°C (typical) drift Power supplies AVDD = 3.0 V to 5.5 V IOVDD = 2 V to 5.5 V Total IDD = 3.9 mA Temperature range: −40°C to +105°C 3-wire or 4-wire serial digital interface (Schmitt trigger on SCLK) SPI, QSPI, MICROWIRE, and DSP compatible

Quad Channel, 256-Position, I2C / SPI, Nonvolatile Digital Potentiometer Features: 10 kΩ and 100 kΩ resistance options Resistor tolerance: 8% maximum Wiper current: ±6 mA Low temperature coefficient: 35 ppm/°C Wide bandwidth: 3 MHz Fast start-up time < 75 μs Linear gain setting mode Single- and dual-supply operation Independent logic supply: 1.8 V to 5.5 V Wide operating temperature: −40°C to +125°C 4 mm × 4 mm package optionAD5144-EP Supports defense and aerospace applications (AQEC standard) Download AD5144-EP data sheet (PDF) Military temperature range (−55°C to +125°C) Controlled manufacturing baseline One assembly/test site One fabrication site Product change notification Qualification data available on request V62/20603
