22.32.0.120.4340
Finder Plc
RELAY DPST-NO 440VAC 25A; Operating Voltage:250V; Contact Configuration:DPST-NO; Relay Mounting:DIN Rail Panel; Coil Voltage VAC Nom:120V; Coil Voltage VDC Nom:120V; Switching Current AC3:10A; Product Range:22 Series
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 2066-22.32.0.120.4340-ND | 21 | $42.93 | $37.50 | $34.12 | $32.76 | $31.04 | $31.04 | |
| element14 APAC | 22.32.0.120.4340 | 2 | 1 | * $38.29 | * $35.46 | * $35.46 | * $35.46 | * $35.46 | * $35.46 |
| Farnell | 22.32.0.120.4340 | 2 | 1 | * $42.35 | * $37.58 | * $34.47 | * $31.99 | * $31.99 | * $31.99 |
| Newark | 22.32.0.120.4340 | 2 | 1 | $49.00 | $42.21 | $37.12 | $37.12 | $37.12 | $37.12 |
38.61.7.024.0050
Finder Plc
RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:24VDC; Contact Current:6A; Product Range:38 Series; Relay Mounting:DIN Rail; Coil Type:DC Sensitive; Contact Voltage VAC:250VAC; Relay Terminals:Cage Clamp; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:CE CSA UL; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BEAB CSA DEMKO IMQ SEMKO SETI SEV UL VDE; Average Power Consumption:300mVA; Coil Voltage VDC Nom:24V; Contact Current AC Max:6A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Current Rating:6A; Dielectric Strength VDC:1000VAC; External Depth:75.6mm; External Height:93.6mm; External Length / Height:93mm; External Width:6.2mm; IP / NEMA Rating:IP20; Mechanical Life:10 000 000 Operations; No. of Mechanical Operations:10000000; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Operating Time:7ms; Relay Type:Interface; Release Time:11ms; Switch Current Max:10A
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 38.61.7.024.0050 | 0 | $16.83 | $16.83 | $16.83 | $16.83 | $16.83 | ||
| element14 APAC | 38.61.7.024.0050 | 163 | 1 | * $17.55 | * $17.55 | * $17.55 | * $17.55 | * $17.55 | * $17.55 |
| Farnell | 38.61.7.024.0050 | 119 | 1 | * $25.75 | * $23.90 | * $22.94 | * $22.94 | * $22.94 | * $22.94 |
| Newark | 38.61.7.024.0050 | 166 | 1 | $25.83 | $23.64 | $22.24 | $21.44 | $21.44 | $21.44 |
| RS Components | 38.61.7.024.0050 | 0 | $22.58 | ||||||
| Rutronik | 38.61.7.024.0050 | 50 | 10 | $9.29 |
38.81.7.024.9024
Finder Plc
RELAY SPST-NO 240VAC 24VDC 2A; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:28.8V; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:19.2V; Control Voltage Min:16.8VDC; Control Voltage Max:30VDC; Product Range:38 Series; SVHC:No SVHC (12-Jan-2017); Approvals & Standards:CE CSA UL; Average Power Consumption:300mVA; Coil Voltage:24VDC; Coil Voltage VDC Nom:24V; Contact Current:2A; Contact Current Max:40A; Contact Voltage DC Max:48V; Contact Voltage VDC:24V; Control Voltage DC Max:30VDC; Control Voltage DC Min:16.8VDC; External Depth:75.6mm; External Height:87.9mm; External Width:6.2mm; Relay Type:Interface
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 38.81.7.024.9024 | 166 | |||||||
| element14 APAC | 38.81.7.024.9024 | 77 | $43.94 | ||||||
| Farnell | 38.81.7.024.9024 | 59 | $41.68 | ||||||
| Newark | 38.81.7.024.9024 | 54 | $34.44 | ||||||
| RS Components | 38.81.7.024.9024 | 0 | $45.85 | ||||||
| TME | 38.81.7.024.9024 | 401 | $32.68 |
39.30.7.024.9024
Finder Plc
RELAY SPST-NO 24VDC 2A; Contact Configuration:SPST-NO; Coil Voltage:24VDC; Contact Current:2A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:DC Sensitive; Contact Voltage VAC:-; Relay Terminals:Screw; Contact Voltage VDC:24VDC; Contact Material:-; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage VDC Nom:24V; Contact Current Max:40A; Contact Voltage DC Max:24V; Control Voltage DC Max:26.4VDC; Control Voltage DC Min:19.2VDC; Control Voltage Max:26.4VDC; Control Voltage Min:19.2VDC; Control Voltage Range:19.2V DC to 26.4V DC; Control Voltage Type:DC; External Depth:90.7mm; External Height:94.3mm; External Width:6.2mm; Input Current:10.5mA; Load Current:2A; Nom Voltage:24V; Operating Voltage Max:24VDC; Operating Voltage Min:1.5VDC; Operating Voltage Range:1.5V DC to 24V DC; Relay Type:Interface
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 39.30.7.024.9024 | 0 | $31.30 | $31.30 | $31.30 | $31.30 | $31.30 | ||
| element14 APAC | 39.30.7.024.9024 | 20 | 1 | * $29.35 | * $29.35 | * $29.35 | * $29.35 | * $29.35 | * $29.35 |
| Farnell | 39.30.7.024.9024 | 20 | 1 | * $49.47 | * $45.91 | * $45.00 | * $45.00 | * $45.00 | * $45.00 |
| Newark | 39.30.7.024.9024 | 19 | 10 | $0.00 | $54.35 | $51.08 | $51.08 | $51.08 | $51.08 |
| RS Components | 39.30.7.024.9024 | 0 | $46.07 |
4C.02.9.024.0050SPA
Finder Plc
RELAY DPDT 250VAC 15A; Contact Configuration:DPDT; Coil Voltage:24VDC; Contact Current:15A; Product Range:4C Series; Relay Mounting:DIN Rail; Coil Type:DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:1.2kohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CE CSA GOST IMQ VDE; Approval Category:UL Recognised; Average Power Consumption:500mW; Coil Current:20mA; Coil Voltage Max:26.4V; Coil Voltage Min:17.5V; Coil Voltage VDC Nom:24V; Contact Current AC Max:15A; Contact Current Max:15A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Current Rating:8A; Dielectric Voltage Contact to Contact:1000VAC; External Depth:64.6mm; External Height:82.9mm; External Length / Height:82.9mm; External Width:15.8mm; IP / NEMA Rating:IP20; No. of Electrical Operations:100000; No. of Mechanical Operations:10000000; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Operating Time:10ms
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 4C.02.9.024.0050SPA | 143 | |||||||
| element14 APAC | 4C.02.9.024.0050SPA | 67 | $29.85 | ||||||
| Farnell | 4C.02.9.024.0050SPA | 43 | $19.70 | ||||||
| Newark | 4C.02.9.024.0050SPA | 15 | $40.96 | ||||||
| RS Components | 4C.02.9.024.0050SPA | 0 | $22.31 | ||||||
| TME | 4C.02.9.024.0050SPA | 214 | $17.68 | ||||||
| Verical Marketplace | 4C.02.9.024.0050SPA | 25 |
39.81.0.024.0060
Finder Plc
RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:24V; Contact Current:6A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:AC / DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Average Power Consumption:250mVA; Coil Voltage VAC Nom:24V; Coil Voltage VDC Nom:24V; Contact Current Max:10A; Contact Voltage AC Nom:250V; Delay Time Range:0.1s to 3s 3s to 60s 1min to 20min 0.3h to 6h; External Depth:90.7mm; External Height:94.3mm; External Width:6.2mm; Input Current Max:19mA; Input Current Min:11mA; Nom Input Voltage:24V; Nom Voltage:24V; Relay Type:Interface; Time Max:6h; Time Min:0.1s; Timing Adjustment:DIP Switch
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 39.81.0.024.0060 | 98 | $31.75 | $30.17 | $30.17 | $25.40 | $25.40 | $25.40 | |
| Farnell | 39.81.0.024.0060 | 4 | 1 | * $33.66 | * $33.66 | * $32.30 | * $31.63 | * $30.96 | * $30.96 |
| Newark | 39.81.0.024.0060 | 2 | 10 | $31.99 | $28.63 | $26.95 | $25.26 | $25.26 | |
| RS Components | 39.81.0.024.0060 | 0 | $47.57 |
40.31.8.120.0000
Finder Plc
RELAY SPDT 250VAC 10A; Contact Configuration:SPDT; Coil Voltage:120VAC; Contact Current:10A; Product Range:40 Series; Relay Mounting:Through Hole; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Coil Current:8.4mA
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 40.31.8.120.0000 | 12080 | $7.23 | $6.31 | $5.74 | $5.51 | $4.89 | $4.89 | |
| element14 APAC | 40.31.8.120.0000 | 84 | 1 | $14.11 | $13.77 | $13.31 | $12.77 | $12.20 | $12.20 |
| Farnell | 40.31.8.120.0000 | 64 | 1 | $8.61 | $7.88 | $7.40 | $7.15 | $7.15 | $7.15 |
| Newark | 40.31.8.120.0000 | 82 | 1 | $10.06 | $9.42 | $7.96 | $7.54 | $7.54 | $7.54 |
40.51.8.024.0000
Finder Plc
RELAY SPDT 250VAC 10A; Contact Configuration:SPDT; Coil Voltage:24VAC; Contact Current:10A; Product Range:40 Series; Relay Mounting:Through Hole; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Coil Current:45mA ;RoHS Compliant: Yes
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 40.51.8.024.0000 | 6 | |||||||
| Newark | 40.51.8.024.0000 | 39 | $7.86 | ||||||
| TE Connectivity | 40.51.8.024.0000 | 0 | |||||||
| TME | 40.51.8.024.0000 | 292 | $6.76 |
40.52.9.012.0000
Finder Plc
RELAY DPDT 250VAC 8A; Contact Configuration:DPDT; Coil Voltage:12VDC; Contact Current:8A; Product Range:40 Series; Relay Mounting:Through Hole; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:-
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 40.52.9.012.0000 | 360 | |||||||
| Arrow Europe | 40.52.9.012.0000 | 124 | |||||||
| element14 APAC | 40.52.9.012.0000 | 776 | $9.71 | ||||||
| Farnell | 40.52.9.012.0000 | 638 | $4.86 | ||||||
| Newark | 40.52.9.012.0000 | 1137 | $4.57 | ||||||
| RS Components | 40.52.9.012.0000 | 0 | $5.92 | ||||||
| Rutronik | 40.52.9.012.0000 | 350 | $3.95 | ||||||
| TE Connectivity | 40.52.9.012.0000 | 0 | |||||||
| TME | 40.52.9.012.0000 | 2770 | $5.82 | ||||||
| Verical Marketplace | 40.52.9.012.0000 | 635 |
40.52.9.024.0000
Finder Plc
RELAY DPDT 250VAC 8A; Contact Configuration:DPDT; Coil Voltage:24VDC; Contact Current:8A; Product Range:40 Series; Relay Mounting:Through Hole; Coil Type:DC; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Coil Current:27mA ;RoHS Compliant: Yes
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 40.52.9.024.0000 | 441 | |||||||
| Newark | 40.52.9.024.0000 | 862 | $7.19 | ||||||
| RS Components | 40.52.9.024.0000 | 0 | $5.92 | ||||||
| Rutronik | 40.52.9.024.0000 | 200 | $3.95 | ||||||
| TE Connectivity | 40.52.9.024.0000 | 0 | |||||||
| TME | 40.52.9.024.0000 | 4737 | $5.82 |
