S8VTF24024E
Omron Automation and Safety
PSU DIN RAIL 240W 24V 3 PHASE; Power Supply Output Type:Fixed; No. of Outputs:1 Output; Input Voltage AC Min:400VAC; Input Voltage AC Max:500VAC; Output Power Max:240W; Output Voltage - Output 1:24VDC; Output Voltage - Output 2:-; Output Current - Output 1:10A; Output Current - Output 2:-; Product Range:-; Output Voltage - Output 3:-; Output Voltage - Output 4:-; Output Current - Output 3:-; Current Output 4:-; Approval Bodies:CSA UL; Approvals / Standards:EN 50178 EN 60204 UL 508; Efficiency:90%; External Depth:130mm; External Length / Height:170mm; External Width:45mm; Frequency Max:60Hz; Frequency Min:50Hz; Height:170mm; Hold Up Time:15ms; Input Current:1A; Input Frequency:60Hz; Input Voltage:500VAC; Length:130mm; No. of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:-10°C; Output Current:10A; Output Ripple Voltage pk-pk:100mV; Output Voltage:24V; Power Rating:240W; Power Supply Type:Switch Mode; Storage Temperature Max:85°C; Storage Temperature Min:-45°C
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | S8VTF24024E | 0 | $428.89 | $428.89 | $428.89 | $428.89 | $428.89 | $428.89 | |
| element14 APAC | S8VTF24024E | 0 | 1 | * $258.00 | * $253.57 | * $253.57 | * $253.57 | * $253.57 | * $253.57 |
| Farnell | S8VTF24024E | 0 | * $271.36 |
E2E-X5E1
Omron Automation and Safety
INDUCTIVE PROXIMITY SENSOR; Sensing Range Max:5mm; Thread Size - Metric:M18; Sensor Output:NPN; Supply Voltage DC Min:10V; Supply Voltage DC Max:30V; Product Range:E2E Series; Sensor Housing:Cylindrical; Sensor Input:Inductive
E32-TC200..
Omron Automation and Safety
PHOTOELECTRIC SENSOR; Fibre Optic Sensor Type:General Purpose; Sensing Range Max:950mm; Sensing Mode:Through-Beam; Sensor Input:Fiber Optic
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | E39-F11-ND | 0 | $66.87 | $54.23 | $50.17 | $48.72 | $48.72 | $48.72 | |
| element14 APAC | E32-TC200.. | 51 | 1 | * $61.44 | * $61.44 | * $61.44 | * $61.44 | * $61.44 | * $61.44 |
| Farnell | E32-TC200.. | 57 | 1 | * $87.63 | * $80.13 | * $76.77 | * $76.77 | * $76.77 | * $76.77 |
E5CN-HV2M-500
Omron Automation and Safety
CONTROLLER TEMP VOLT; Thermocouple Type:B E J K L N R S T W PLII; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Temperature Accuracy ±:-; Output Voltage Max:10VDC; Output Voltage Min:0VDC; Product Range:-; Accuracy:0.1%; Approval Bodies:CE; Approval Category:UL Recognised; Colour:Black; External Depth:91mm; External Length / Height:48mm; External Width:48mm; Input:Thermocouple PRT Current or Voltage; No. of Inputs:2; No. of Outputs:3Outputs; Output:2 x Auxiliary; Output Type:Linear Voltage; Power Consumption:8.5VA; Storage Temperature Max:65°C; Storage Temperature Min:-25°C; Supply Voltage Max:240VAC; Supply Voltage Min:100VAC
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | E5CN-HV2M-500 | 0 | |||||||
| element14 APAC | E5CN-HV2M-500 | 5 | 1 | * $830.05 | * $830.05 | * $830.05 | * $830.05 | * $830.05 | * $830.05 |
| Farnell | E5CN-HV2M-500 | 6 | 1 | * $552.40 | * $552.40 | * $552.40 | * $552.40 | * $552.40 | * $552.40 |
E53-C3DN
Omron Automation and Safety
OUTPUT UNIT 0-20MA OUTPUT; Current Rating:20mA; Product Range:-; Accessory Type:Output Unit - Linear 0-20 mA; For Use With:E5EN-H and E5AN-H Controllers; No. of Analogue Outputs:1
MKS2PIAC24
Omron Automation and Safety
RELAY DPDT 250VAC 30VDC 10A; Contact Configuration:DPDT; Coil Voltage:24VAC; Contact Current:10A; Product Range:-; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:48.4ohm; Approvals & Standards:-; AC Coil Power:2.7VA; Coil Current:110mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:24V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:30V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:2.7VA; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Operating Time:20ms; Relay Type:Power; Release Time:20ms
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | MKS2PIAC24 | 10 | $17.90 | $15.94 | $14.70 | $14.20 | $13.09 | $13.09 | |
| element14 APAC | MKS2PIAC24 | 1 | 1 | * $18.89 | * $17.85 | * $16.46 | * $16.46 | * $16.46 | * $16.46 |
| Farnell | MKS2PIAC24 | 1 | 1 | * $13.07 | * $12.33 | * $11.66 | * $11.66 | * $11.66 | * $11.66 |
MKS2PIDC24
Omron Automation and Safety
RELAY DPDT 250VAC 30VDC 10A; Contact Configuration:DPDT; Coil Voltage:24VDC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:430ohm; Approvals & Standards:-; Coil Current:55.8mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VDC Nom:24V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:1.4W; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | MKS2PIDC24 | 10 | $18.40 | $16.39 | $15.11 | $14.59 | $13.46 | $13.46 | |
| element14 APAC | MKS2PIDC24 | 4 | 1 | * $10.07 | * $10.07 | * $9.67 | * $9.67 | * $9.67 | * $9.67 |
| Farnell | MKS2PIDC24 | 4 | 1 | * $8.86 | * $8.21 | * $8.05 | * $8.05 | * $8.05 | * $8.05 |
MKS3PI5AC24
Omron Automation and Safety
RELAY 3PDT 250VAC 30VDC 10A; Contact Configuration:3PDT; Coil Voltage:24VAC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:62ohm; Approvals & Standards:-; Coil Current:110mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:24V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:2.7VA; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | MKS3PI5AC24 | 2 | $24.58 | $21.89 | $20.19 | $19.49 | $14.82 | $14.82 | |
| element14 APAC | MKS3PI5AC24 | 7 | 1 | * $21.53 | * $17.65 | * $16.75 | * $16.75 | * $16.75 | * $16.75 |
| Farnell | MKS3PI5AC24 | 7 | 1 | * $14.64 | * $13.81 | * $13.07 | * $13.07 | * $13.07 | * $13.07 |
MKS3PI5AC230
Omron Automation and Safety
RELAY 3PDT 250VAC 30VDC 10A; Contact Configuration:3PDT; Coil Voltage:230VAC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:6.17kohm; Approvals & Standards:-; Coil Current:11.5mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:230V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:2.7VA; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | MKS3PI5AC230 | 0 | 1 | $26.32 | $26.32 | $26.32 | $26.32 | $26.32 | $26.32 |
| element14 APAC | MKS3PI5AC230 | 18 | 1 | * $13.98 | * $13.98 | * $13.74 | * $13.74 | * $13.74 | * $13.74 |
| Farnell | MKS3PI5AC230 | 20 | 1 | * $20.18 | * $16.49 | * $15.84 | * $13.25 | * $13.25 | * $13.25 |
MKS3PI5DC24
Omron Automation and Safety
RELAY 3PDT 250VAC 30VDC 10A; Contact Configuration:3PDT; Coil Voltage:24VDC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:430ohm; Approvals & Standards:-; Coil Current:55.8mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VDC Nom:24V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:1.4W; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | Z3218-ND | 16 | $20.87 | $18.59 | $17.14 | $16.55 | $15.26 | $15.26 | |
| element14 APAC | MKS3PI5DC24 | 22 | 1 | * $17.02 | * $17.02 | * $16.78 | * $16.78 | * $16.78 | * $16.78 |
| Farnell | MKS3PI5DC24 | 36 | 1 | * $10.55 | * $10.55 | * $10.55 | * $10.55 | * $10.55 | * $10.55 |
