ADAPTOR PANEL MOUNTING; Product Range:Y92 Series; Relay Clip Type:Frame; For Use With:H5C Series Motor Timer; Accessory Type:Panel Mount Adapter; Material:Polycarbonate

TIMER ON-DELAY 230VAC 10M; Product Range:-; Timer Functions:Reset; No. of Timing Ranges:1Ranges; Time Min:0.5min; Time Max:10min; Timer Output:Solid State; Supply Voltage Max:230VAC; Current Rating Nom:3A; Connection / Termination:Plug-In; Panel Cutout Height:25.8mm; Panel Cutout Width:21.4mm; Adjustment Type:Rotary; Coil Voltage VAC Nom:230V; Contact Configuration:4PDT; Contact Current AC Max:3A; Contact Voltage AC Max:250V; Delay Time Range:0.5min to 10min; External Depth:27.2mm; External Length / Height:56.6mm; External Width:20.7mm; Height:56.6mm; No. of Pins:14Pins; Nom Input Voltage:230VAC; Operating Time Range:0.5min to 10min; Relay Mounting:Quick Connect; Repeat Accuracy +:2%; Reset Time:0.1s; Supply Voltage AC Max:230V; Supply Voltage AC Min:200V; Switch Current Max:3A; Switching Current Max:3A; Timing Adjustment:Knob

TIMER ON-DELAY 24VDC 30M; Product Range:H3Y Series; Timer Functions:Reset; No. of Timing Ranges:1Ranges; Time Min:1min; Time Max:30min; Timer Output:Solid State; Supply Voltage Max:24VDC; Current Rating Nom:3A; Connection / Termination:Plug-In; Panel Cutout Height:25.8mm; Panel Cutout Width:21.4mm; Adjustment Type:Rotary; Coil Voltage VDC Nom:24V; Contact Configuration:4PDT; Contact Current AC Max:3A; Contact Voltage AC Max:250V; Delay Time Range:1min to 30min; External Depth:27.2mm; External Length / Height:56.6mm; External Width:20.7mm; Height:56.6mm; No. of Pins:14Pins; Nom Input Voltage:24VDC; Operating Time Range:1-30m; Relay Mounting:Quick Connect; Repeat Accuracy +:2%; Reset Time:0.1s; Supply Voltage AC Max:27.6V; Supply Voltage AC Min:20.4V; Supply Voltage V AC:24V; Supply Voltage V DC:24V; Switch Current Max:3A; Switching Current Max:3A; Timing Adjustment:Knob

TIMER ON-DELAY; Product Range:H5CN-XCNM Series; Timer Functions:On-Delay; Time Min:1s; Time Max:99.98min; No. of Timing Ranges:1Ranges; No. of Digits:4; Timer Output:1 Changeover Relay; Supply Voltage Max:240VAC; Current Rating Nom:3A; Connection / Termination:Plug-In; Panel Cutout Height:45mm; Panel Cutout Width:45mm; Adjustment Type:Pushbutton; Coil Voltage VAC Nom:240V; Coil Voltage VDC Nom:24V; Contact Configuration:SPDT; Contact Current AC Max:3A; Contact Rating:3A; Contact Voltage AC Max:250V; Delay Time Range:1s to 99.59min; External Depth:86mm; External Length / Height:48mm; External Width:48mm; Height:48mm; No. of Pins:11Pins; Nom Input Voltage:240V; Operating Time Range:1s to 99m 59s; Relay Mounting:Panel; Repeat Accuracy +:0.1%; Reset Time:0.02s; Supply Voltage AC Min:100VAC; Supply Voltage V AC:240V; Switch Current Max:3A; Switching Current Max:3A; Timing Adjustment:Pushbutton; Voltage Rating VAC:240V

RELAY SPDT 240VAC 30VDC 15A; Contact Configuration:SPDT; Coil Voltage:12VDC; Contact Current:15A; Product Range:LY Series; Relay Mounting:Through Hole; Coil Type:Non Latching; Contact Voltage VAC:240VAC; Relay Terminals:Solder

MICROSWITCH PLUNGER; Microswitch Type:Snap Action; Microswitch Actuator:Plunger; Contact Configuration:SPDT; Switch Terminals:Solder; Contact Current Max:7A; Contact Voltage DC Nom:250VDC; Product Range:J7 Series; Contact Voltage AC Nom:240VAC; Operating Force Max:1.37N; Actuation Type:Plunger; Actuator Type:Plunger; Contact Current AC:5A; Contact Current AC Max:7A; Contact Current DC Max:7A; Contact Voltage AC Max:250V; Contact Voltage DC Max:250V; Differential Travel Max:0.15mm; External Depth:12.7mm; External Length / Height:8.9mm; External Width:5.1mm; Fixing Centres:4.8mm; Fixing Centres LxW:5mm; No. of Electrical Operations:50000; No. of Mechanical Operations:50000; Operating Force:1.4N; Operating Temperature Max:80°C; Operating Temperature Min:-25°C; Over Travel Min:0.1mm; Pre-travel:0.6mm; Return Force Min:0.28gf

LIMIT SWITCH PISTON PLUNGER; Limit Switch Actuator:Top Plunger; Contact Configuration:1NO; Contact Current AC Max:10A; Contact Voltage AC Max:500V; Operating Force Max:26.67N; Product Range:WL Series; Contact Current DC Max:10A; Contact Voltage DC Max:250V; Actuator Type:Plunger; Contact Current Rating:10A; External Depth:40mm; External Length / Height:94.1mm; External Width:39.9mm; Fixing Centres LxW:58.7 x 30.2; IP / NEMA Rating:IP67; No. of Electrical Operations:800000; No. of Mechanical Operations:15000000; Operating Force:26.67N; Operating Temperature Max:80°C; Operating Temperature Min:-5°C; Pre-travel:1.7mm; Switch Terminals:Screw; Thermal Current Rating:10A

SWITCH PLUNGER; Limit Switch Actuator:Plunger; Contact Configuration:SPDT; Contact Current AC Max:10A; Contact Voltage AC Max:250V; Operating Force Max:11.77N; Product Range:ZC Series; Contact Current DC Max:10A; Contact Voltage DC Max:250V; Actuator Type:Pin Plunger; Contact Current Rating:10A; External Depth:60mm; External Length / Height:37mm; External Width:21.4mm; Fixing Centres:25.4mm; No. of Electrical Operations:750000; No. of Mechanical Operations:10000000; Operating Force:11.77N; Operating Temperature Max:80°C; Operating Temperature Min:-10°C; Pre-travel:1.6mm; Switch Terminals:Screw; Thermal Current Rating:10A; Voltage:240V

SWITCH ROLLER ARM; Limit Switch Actuator:Roller Lever; Contact Configuration:SPDT; Contact Current AC Max:15A; Contact Voltage AC Max:480V; Operating Force Max:6.28N; Product Range:ZE Series; Contact Current DC Max:500mA; Contact Voltage DC Max:250V; Actuator Type:Roller Arm Lever; Contact Current Rating:15A; External Depth:25.4mm; External Length / Height:44.5mm; External Width:86mm; Fixing Centres:25.4mm; IP / NEMA Rating:IP65; No. of Electrical Operations:700000; No. of Mechanical Operations:10000000; Operating Force:3.43N; Operating Temperature Max:80°C; Operating Temperature Min:-5°C; Pre-travel:0.5mm; Switch Terminals:Screw; Thermal Current Rating:15A

ACTUATOR FLEXIBLE; For Use With:WL Series Two-Circuit Limit Switches; IP / NEMA Rating:-; Product Range:-
